Артикул
Название
Примечание
Количество
|$$1
SERIAL NO. IN ( ) INDICATES TRANSMISSION SERIAL NO.
-1шт.
|$3
14X-15-21002
TRANSMISSION ASS'Y
SN: 4934-UP
1шт.
|$4
14X-15-21001
TRANSMISSION ASS'Y
SN: 4001-4933
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.F2320-51A0A TO F2320-62A0A
-1шт.
1
14X-15-21150
HOUSING
SN: 4001-UP
1шт.
3
14X-15-22750
PISTON
SN: 4001-UP
1шт.
9
14X-15-22640
RING GEAR
SN: 4001-UP
1шт.
10
14X-15-22780
PLATE
SN: 4001-UP
5шт.
11
14X-15-22710
DISC
SN: 4001-UP
4шт.
12
14X-15-21160
HOUSING
SN: 4001-UP
1шт.
17
14X-15-29220
SEAL RING (K2)
SN: 4001-UP
1шт.
19
14X-15-22661
RING GEAR
SN: (101295)-UP
1шт.
19
14X-15-22660
RING GEAR
SN: 4001-(101293)
1шт.
20
14X-15-22780
PLATE
SN: 4001-UP
8шт.
21
14X-15-22710
DISC
SN: 4001-UP
7шт.
22
14X-15-12910
SPRING
SN: 4001-UP
5шт.
26
14X-15-21170
HOUSING
SN: 4001-UP
1шт.
30
14X-15-22740
PISTON
SN: 4001-UP
1шт.
32
14X-15-22770
PISTON
SN: 4001-UP
1шт.
34
14X-15-12910
SPRING
SN: 4001-UP
5шт.
36
14X-15-22780
PLATE
SN: 4001-UP
6шт.
37
14X-15-22710
DISC
SN: 4001-UP
5шт.
38
14X-15-21180
HOUSING
SN: 4001-UP
1шт.
40
14X-15-29230
SEAL RING (K2)
SN: 4001-UP
1шт.
41
145-14-11571
WASHER
SN: 4001-UP
14шт.
42
144-15-21191
BOLT
SN: 4001-UP
3шт.
44
14X-15-22371
COVER
SN: 4934-UP
1шт.
44
14X-15-22370
COVER
SN: 4001-4933
1шт.
45
14X-15-29230
SEAL RING (K2)
SN: 4001-UP
1шт.
Выбрано товаров: 55
