Запчасти Komatsu D85E-SS-2 ТРАНСМИССИЯ (3 МУФТА И 2 МУФТА) СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$1

14X-15-00012

TRANSMISSION ASS'Y

Field_1: J10241-

1шт.

|$2

14X-15-00250

HOUSING ASS'Y

Field_1: J10241-

1шт.

1

0

HOUSING

Field_1: J10241-

1шт.

2

145-14-11320

HOUSING ASS'Y

Field_1: J10241-

1шт.

|$5

14X-15-00240

HOUSING

Field_1: J10241-

1шт.

3

0

PLUG

Field_1: J10241-

1шт.

4

145-14-11320

PLUG

Field_1: J10241-

1шт.

5

07000-72020

O-RING (K3)

Field_1: J10241-

1шт.

6

04020-01228

PIN

Field_1: J10241-

2шт.

7

14X-15-12240

GEAR

Field_1: J10241-

1шт.

8

14X-15-12160

SPACER

Field_1: J10241-

1шт.

9

04064-05520

SNAP RING

Field_1: J10241-

1шт.

10

14X-15-19310

BEARING

Field_1: J10241-

1шт.

11

14X-15-12330

CARRIER

Field_1: J10241-

1шт.

12

14X-15-12530

SHAFT

Field_1: J10241-

3шт.

13

04260-00635

BALL

Field_1: J10241-

3шт.

14

14X-15-12430

GEAR

Field_1: J10241-

3шт.

15

14X-15-12520

SHAFT

Field_1: J10241-

3шт.

16

04025-00620

PIN

Field_1: J10241-

3шт.

17

14X-15-12440

GEAR

Field_1: J10241-

3шт.

18

14X-15-19420

BEARING

Field_1: J10241-

6шт.

19

154-15-12550

WASHER, THRUST

Field_1: J10241-

12шт.

20

04055-07225

SNAP RING

Field_1: J10241-

1шт.

21

07018-12105

SEAL RING (K3)

Field_1: J10241-

1шт.

22

14X-15-19510

SNAP RING

Field_1: J10241-

1шт.

23

14X-15-12640

GEAR, RING

Field_1: J10241-

1шт.

24

14X-15-12670

GEAR, RING

Field_1: J10241-

1шт.

25

424-15-12750

PISTON

Field_1: J10241-

1шт.

26

424-15-12760

PISTON

Field_1: J10241-

1шт.

27

568-15-12850

SEAL RING (K3)

Field_1: J10241-

1шт.

28

144-15-22881

SEAL RING (K3)

Field_1: J10241-

1шт.

29

113-15-12870

SEAL RING (K3)

Field_1: J10241-

2шт.

30

424-15-12711

DISC

Field_1: J10241-

6шт.

31

424-15-12720

PLATE

Field_1: J10241-

4шт.

32

103-15-22911

SPRING

Field_1: J10241-

20шт.
