Запчасти Komatsu D85E-SS-2 ТЯГОВ. ЛЕБЕДКА (КОРПУС) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

07043-00108

PLUG

Field_1: J10001-

1шт.

2

04020-01228

DOWEL PIN

Field_1: J10001-

2шт.

3

14X-960-3850

COVER

Field_1: J10001-

1шт.

4

01010-81245

BOLT

Field_1: J10001-

11шт.

5

01643-31232

WASHER

Field_1: J10001-

11шт.

6

14X-960-3812

CASE ASS'Y

Field_1: J10001-J10483

1шт.

|$7

14X-960-3813

CASE ASS'Y

Field_1: J10484-

1шт.

|$8

14X-960-8210

CASE (WITH FAIR LEAD)

Field_1: J10001-J10483

1шт.

|$9

14X-960-8212

CASE (WITH FAIR LEAD)

Field_1: J10484-

1шт.

7

14X-960-8220

BRACKET, L.H. (WITH FAIR LEAD)

Field_1: J10001-J10483

1шт.

|$11

14X-960-8221

BRACKET, L.H. (WITH FAIR LEAD)

Field_1: J10484-

1шт.

8

14X-960-8230

BRACKET, R.H. (WITH FAIR LEAD)

Field_1: J10001-J10483

1шт.

|$13

14X-960-8231

BRACKET, R.H. (WITH FAIR LEAD)

Field_1: J10484-

1шт.

9

14X-960-8240

PLATE, (WITH FAIR LEAD)

Field_1: J10001-

2шт.

10

07044-13620

PLUG

Field_1: J10001-

1шт.

11

07002-03634

O-RING

Field_1: J10001-

1шт.

12

144-916-1820

PLUG

Field_1: J10001-

1шт.

13

07043-00108

PLUG

Field_1: J10001-

1шт.

14

09601-00835

NAME PLATE

Field_1: J10001-

1шт.

15

04418-13060

SCREW

Field_1: J10001-

4шт.

16

14X-960-3750

COVER

Field_1: J10001-J10483

1шт.

|$22

14X-960-3751

COVER

Field_1: J10484-

1шт.

17

01010-81230

BOLT

Field_1: J10001-

12шт.

18

01643-31232

WASHER

Field_1: J10001-

12шт.

19

07040-13618

PLUG

Field_1: J10001-

1шт.

20

07002-03634

O-RING

Field_1: J10001-

1шт.

21

07030-00252

BREATHER

Field_1: J10001-

1шт.

22

14W-960-7190

BRACKET

Field_1: J10001-J10483

1шт.

|$29

14X-960-6450

BRACKET

Field_1: J10484-

1шт.

23

01010-81235

BOLT

Field_1: J10001-

2шт.

24

01643-31232

WASHER

Field_1: J10001-

2шт.

25

14X-960-3870

COVER

Field_1: J10001-

1шт.

26

14W-960-7220

BRACKET

Field_1: J10001-

1шт.

27

01010-81235

BOLT

Field_1: J10001-

8шт.

28

01010-81260

BOLT

Field_1: J10001-

2шт.

29

01643-31232

WASHER

Field_1: J10001-

10шт.

30

14X-960-3731

BAR

Field_1: J10001-

1шт.

31

176-43-54481

WASHER

Field_1: J10001-

2шт.

32

04050-00060

COTTER PIN

Field_1: J10001-

2шт.
