Запчасти Komatsu D85E-SS-2 ГИДРОЦИЛИНДР ПОДЪЕМА РАБОЧЕЕ ОБОРУДОВАНИЕ

G-1

Ѓќ14Y-63-X1114

CYLINDER GROUP, LIFT, L.H.

Field_1: J10001-

1шт.

G-1

Ѓќ14Y-63-X1124

CYLINDER GROUP, LIFT, R.H.

Field_1: J10001-

1шт.

|$3

14Y-63-01013

CYLINDER ASS'Y

Field_1: J10001-

2шт.

1

14Y-63-12143

CYLINDER

Field_1: J10001-

1шт.

2

707-29-95730

HEAD

Field_1: J10001-

1шт.

3

707-52-10660

BUSHING

Field_1: J10001-

1шт.

4

707-51-65211

PACKING (K8)

Field_1: J10001-

1шт.

5

07000-02095

O-RING (K8)

Field_1: J10001-

1шт.

6

07000-12090

O-RING (K8)

Field_1: J10001-

1шт.

7

707-35-52780

RING (K8)

Field_1: J10001-

1шт.

8

144-63-92170

DUST SEAL (K8)

Field_1: J10001-

1шт.

9

07179-12079

SNAP RING

Field_1: J10001-

1шт.

10

14Y-63-12121

ROD

Field_1: J10001-

1шт.

11

707-66-70020

CAP

Field_1: J10001-

1шт.

12

01011-51600

BOLT

Field_1: J10001-

4шт.

13

01643-51645

WASHER

Field_1: J10001-

4шт.

14

707-88-11290

SHIM

Field_1: J10001-

6шт.

14A

707-88-11300

SHIM

Field_1: J10001-

6шт.

|$19

14Y-63-12131

PISTON ASS'Y

Field_1: J10001-

1шт.

15

707-37-95010

PISTON

Field_1: J10001-

1шт.

16

0

VALVE, PISTON

Field_1: J10001-

1шт.

17

0

VALVE, PISTON

Field_1: J10001-

1шт.

18

0

VALVE, PISTON

Field_1: J10001-

2шт.

19

0

SEAT, VALVE

Field_1: J10001-

8шт.

20

707-44-95180

RING (K8)

Field_1: J10001-

1шт.

21

707-69-95010

SLIDER

Field_1: J10001-

1шт.

22

707-39-95120

WEAR RING (K8)

Field_1: J10001-

2шт.

23

130-63-12761

PIN

Field_1: J10001-

2шт.

24

707-40-95010

RETAINER

Field_1: J10001-

2шт.

25

707-68-10330

NUT

Field_1: J10001-

1шт.

26

144-60-15450

BUSHING

Field_1: J10001-

4шт.

27

144-60-15431

BUSHING

Field_1: J10001-

4шт.

28

07145-00055

DUST SEAL (K8)

Field_1: J10001-

4шт.

29

14Y-63-12181

TUBE

Field_1: J10001-

1шт.

|$35

14Y-63-12281

TUBE

Field_1: J10001-

1шт.

30

14Y-63-12172

TUBE

Field_1: J10001-

1шт.

|$37

14Y-63-12270

TUBE

Field_1: J10001-

1шт.

31

07372-21040

BOLT

Field_1: J10001-

4шт.

32

07000-13030

O-RING (K8)

Field_1: J10001-

2шт.

33

07372-21050

BOLT

Field_1: J10001-

4шт.

34

01643-51032

WASHER

Field_1: J10001-

8шт.

35

07283-22738

CLIP

Field_1: J10001-

4шт.

36

01599-01011

NUT

Field_1: J10001-

8шт.

37

01643-31032

WASHER

Field_1: J10001-

8шт.

38

01010-81020

BOLT

Field_1: J10001-

2шт.

39

01643-31032

WASHER

Field_1: J10001-

2шт.
