Запчасти Komatsu D85E-SS-2 ГУСЕНИЧНАЯ РАМА ХОДОВАЯ

|$1

14U-30-00011

TRACK FRAME ASS'Y, L.H.

Field_1: J10001-J11240

1шт.

|$2

14U-30-00012

TRACK FRAME ASS'Y, L.H.

Field_1: J11241-J10774

1шт.

|$3

14U-30-00013

TRACK FRAME ASS'Y, L.H.

Field_1: J10775-

1шт.

|$4

14U-30-00021

TRACK FRAME ASS'Y, R.H.

Field_1: J10001-J11240

1шт.

|$5

14U-30-00022

TRACK FRAME ASS'Y, R.H.

Field_1: J11241-J10774

1шт.

|$6

14U-30-00023

TRACK FRAME ASS'Y, R.H.

Field_1: J10775-

1шт.

1

14U-30-11112

FRAME, L.H.

Field_1: J10001-J11240

1шт.

|$8

14U-30-11113

FRAME, L.H.

Field_1: J11241-J10774

1шт.

|$9

14U-30-J1110

FRAME, L.H.

Field_1: J10775-

1шт.

|$10

14U-30-11122

FRAME, R.H.

Field_1: J10001-J11240

1шт.

|$11

14U-30-11123

FRAME, R.H.

Field_1: J11241-J10774

1шт.

|$12

14U-30-J1120

FRAME, R.H.

Field_1: J10775-

1шт.

2

14X-30-11292

GUARD, L.H. (WELDED)

Field_1: J10001-

1шт.

|$14

14X-30-11312

GUARD, R.H. (WELDED)

Field_1: J10001-

1шт.

3

14X-30-11312

GUARD, L.H. (WELDED)

Field_1: J10001-

1шт.

|$16

14X-30-11292

GUARD, R.H. (WELDED)

Field_1: J10001-

1шт.

4

14X-30-11D50

PLATE (WELDED)

Field_1: J10001-J11240

1шт.

|$18

14X-30-11D51

PLATE (WELDED)

Field_1: J11241-

1шт.

5

14X-30-11D60

PLATE (WELDED)

Field_1: J10001-J11240

2шт.

|$20

14X-30-11D61

PLATE (WELDED)

Field_1: J11241-

2шт.

5A

14X-30-11D90

PLATE (WELDED)

Field_1: J10001-J11240

1шт.

|$22

14X-30-11D92

PLATE (WELDED)

Field_1: J11241-

1шт.

6

14Y-30-18130

BUSHING

Field_1: J10001-

1шт.

7

14Y-30-18140

BUSHING

Field_1: J10001-

1шт.

8

14Y-50-11450

BUSHING

Field_1: J10001-J10774

1шт.

|$26

14Y-50-11521

BUSHING

Field_1: J10775-

1шт.

9

14Y-30-16133

GUARD

Field_1: J10001-

2шт.

10

01010-81845

BOLT

Field_1: J10001-

12шт.

11

01643-31845

WASHER

Field_1: J10001-

12шт.

12

14X-30-11361

BRACKET, L.H.

Field_1: J10001-J10264

1шт.

|$31

14X-30-11362

BRACKET, L.H.

Field_1: J10265-

2шт.

|$32

14X-30-11351

BRACKET, R.H.

Field_1: J10001-J10264

1шт.

|$33

14X-30-11352

BRACKET, R.H.

Field_1: J10265-

2шт.

13

01010-81845

BOLT

Field_1: J10265-

8шт.

14

01010-81865

BOLT

Field_1: J10265-

8шт.

15

01643-31845

WASHER

Field_1: J10265-

16шт.

16

07049-01822

PLUG

Field_1: J10001-J10264

4шт.

17

14Y-30-11277

COVER

Field_1: J10001-

2шт.

18

01010-81225

BOLT

Field_1: J10001-

4шт.

19

01643-31232

WASHER

Field_1: J10001-

4шт.

20

07049-01215

PLUG

Field_1: J10001-

8шт.

21

07049-01822

PLUG

Field_1: J10001-

10шт.
