Запчасти Komatsu 6D140-1A ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|1

6210-71-1111

INJECTION PUMP ASS'Y

SN: 14715-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 11200-14714

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105663-0380

COUPLING ASS'Y

SN: 11200-UP

1шт.

1

DK156630-6600

COUPLING

SN: 11200-UP

1шт.

2

DK156633-8200

BOLT

SN: 11200-UP

2шт.

3

DK156615-2800

WASHER

SN: 11200-UP

2шт.

4

DK156605-5320

PLATE

SN: 11200-UP

2шт.

5

DK156617-2100

NUT

SN: 11200-UP

2шт.

6

DK156633-3300

BOLT

SN: 11200-UP

4шт.

7

DK156609-6300

COUPLING,CROSS

SN: 11200-UP

1шт.

8

DK156633-8300

BOLT

SN: 11200-UP

2шт.

9

DK156633-8400

BOLT

SN: 11200-UP

1шт.

|1

6210-71-1111

INJECTION PUMP ASS'Y

SN: 14715-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 11200-14714

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105663-0380

COUPLING ASS'Y

SN: 11200-UP

1шт.

1

DK156630-6600

COUPLING

SN: 11200-UP

1шт.

2

DK156633-8200

BOLT

SN: 11200-UP

2шт.

3

DK156615-2800

WASHER

SN: 11200-UP

2шт.

4

DK156605-5320

PLATE

SN: 11200-UP

2шт.

5

DK156617-2100

NUT

SN: 11200-UP

2шт.

6

DK156633-3300

BOLT

SN: 11200-UP

4шт.

7

DK156609-6300

COUPLING,CROSS

SN: 11200-UP

1шт.

8

DK156633-8300

BOLT

SN: 11200-UP

2шт.

9

DK156633-8400

BOLT

SN: 11200-UP

1шт.
