Запчасти Komatsu 6D140-1A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|1

6210-71-1111

INJECTION PUMP ASS'Y

SN: 14715-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 11200-14714

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105407-3591

GOVERNOR ASS'Y

SN: 14715-UP

1шт.

|1

0

GOVERNOR ASS'Y

SN: 11200-14714

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.

-1шт.

1

DK154500-8320

COVER

SN: 11200-UP

1шт.

2

DK154031-4300

SCREW

SN: 11200-UP

1шт.

3

DK139208-0500

NUT

SN: 11200-UP

1шт.

4

DK020106-5040

BOLT

SN: 11200-UP

2шт.

5

DK154010-5220

CAPSULE,SPRING

SN: 11200-UP

1шт.

6

DK154011-1900

NUT

SN: 11200-UP

1шт.

7

DK020106-3840

BOLT

SN: 11200-UP

4шт.

8

DK154063-7300

COVER

SN: 11200-UP

1шт.

9

DK029020-6210

BOLT

SN: 11200-UP

2шт.

10

DK020006-1640

BOLT

SN: 11200-UP

2шт.

11

DK154150-6400

SPRING,GOVERNOR

SN: 11200-UP

1шт.

12

DK154158-3420

CAPSULE,SPRING

SN: 11200-UP

1шт.

13

DK154011-1700

NUT

SN: 11200-UP

1шт.

14

DK026512-1540

GASKET

SN: 11200-UP

2шт.

15

DK154159-1200

NUT,CAP

SN: 11200-UP

1шт.

16

DK154200-7020

LEVER ASS'Y,SWIVEL

SN: 14715-UP

1шт.

|16

DK154200-0220

LEVER ASS'Y,SWIVEL

SN: 11200-14714

1шт.

17

DK154204-3000

BUSHING

SN: 14715-UP

1шт.

|17

DK154204-1900

BUSHING

SN: 11200-14714

1шт.

18

DK139718-0200

O-RING

SN: 14715-UP

2шт.

|18

DK029631-8020

O-RING

SN: 11200-14714

2шт.

19

DK016010-1640

RING,SNAP

SN: 11200-UP

2шт.

20

DK139611-0000

SEAL,OIL

SN: 11200-UP

1шт.

21

DK139411-0000

SHIM¤ 0.40MM

SN: 11200-UP

1шт.

22

DK029311-1090

SHIM¤ 0.30MM

SN: 11200-UP

-2шт.

23

DK154204-3100

BUSHING

SN: 14715-UP

1шт.

|23

DK154204-1200

BUSHING

SN: 11200-14714

1шт.

24

DK025803-1310

KEY¤ 13MM

SN: 11200-UP

1шт.

25

DK154206-2800

COLLAR

SN: 11200-UP

1шт.

26

DK154206-0200

WASHER¤ 1.0MM

SN: 11200-UP

-2шт.

27

DK154237-1700

PIN

SN: 11200-UP

1шт.

28

DK154342-7020

LEVER

SN: 14715-UP

1шт.

|28

DK154347-9120

LEVER

SN: 11200-14714

1шт.

29

DK154314-2500

SPRING

SN: 11200-UP

1шт.

30

DK154350-7800

GASKET

SN: 11200-UP

1шт.

31

DK029635-2020

O-RING

SN: 11200-UP

1шт.

32

DK026508-1140

GASKET

SN: 11200-UP

2шт.

33

DK154035-2000

NUT,CAP

SN: 11200-UP

1шт.

34

DK154036-1600

ADAPTER

SN: 11200-UP

1шт.

35

DK139806-0000

BOLT,EYE

SN: 11200-UP

1шт.

36

DK029340-6120

GASKET

SN: 11200-UP

2шт.

37

DK029331-0090

GASKET

SN: 14715-UP

1шт.

|37

DK026510-1340

GASKET

SN: 11200-14714

1шт.

|1

6210-71-1111

INJECTION PUMP ASS'Y

SN: 14715-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 11200-14714

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105407-3591

GOVERNOR ASS'Y

SN: 14715-UP

1шт.

|1

0

GOVERNOR ASS'Y

SN: 11200-14714

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461 AND 0462.

-1шт.

1

DK154500-8320

COVER

SN: 11200-UP

1шт.

2

DK154031-4300

SCREW

SN: 11200-UP

1шт.

3

DK139208-0500

NUT

SN: 11200-UP

1шт.

4

DK020106-5040

BOLT

SN: 11200-UP

2шт.

5

DK154010-5220

CAPSULE,SPRING

SN: 11200-UP

1шт.

6

DK154011-1900

NUT

SN: 11200-UP

1шт.

7

DK020106-3840

BOLT

SN: 11200-UP

4шт.

8

DK154063-7300

COVER

SN: 11200-UP

1шт.

9

DK029020-6210

BOLT

SN: 11200-UP

2шт.

10

DK020006-1640

BOLT

SN: 11200-UP

2шт.

11

DK154150-6400

SPRING,GOVERNOR

SN: 11200-UP

1шт.

12

DK154158-3420

CAPSULE,SPRING

SN: 11200-UP

1шт.

13

DK154011-1700

NUT

SN: 11200-UP

1шт.

14

DK026512-1540

GASKET

SN: 11200-UP

2шт.

15

DK154159-1200

NUT,CAP

SN: 11200-UP

1шт.

16

DK154200-7020

LEVER ASS'Y,SWIVEL

SN: 14715-UP

1шт.

|16

DK154200-0220

LEVER ASS'Y,SWIVEL

SN: 11200-14714

1шт.

17

DK154204-3000

BUSHING

SN: 14715-UP

1шт.

|17

DK154204-1900

BUSHING

SN: 11200-14714

1шт.

18

DK139718-0200

O-RING

SN: 14715-UP

2шт.

|18

DK029631-8020

O-RING

SN: 11200-14714

2шт.

19

DK016010-1640

RING,SNAP

SN: 11200-UP

2шт.

20

DK139611-0000

SEAL,OIL

SN: 11200-UP

1шт.

21

DK139411-0000

SHIM¤ 0.40MM

SN: 11200-UP

1шт.

22

DK029311-1090

SHIM¤ 0.30MM

SN: 11200-UP

-2шт.

23

DK154204-3100

BUSHING

SN: 14715-UP

1шт.

|23

DK154204-1200

BUSHING

SN: 11200-14714

1шт.

24

DK025803-1310

KEY¤ 13MM

SN: 11200-UP

1шт.

25

DK154206-2800

COLLAR

SN: 11200-UP

1шт.

26

DK154206-0200

WASHER¤ 1.0MM

SN: 11200-UP

-2шт.

27

DK154237-1700

PIN

SN: 11200-UP

1шт.

28

DK154342-7020

LEVER

SN: 14715-UP

1шт.

|28

DK154347-9120

LEVER

SN: 11200-14714

1шт.

29

DK154314-2500

SPRING

SN: 11200-UP

1шт.

30

DK154350-7800

GASKET

SN: 11200-UP

1шт.

31

DK029635-2020

O-RING

SN: 11200-UP

1шт.

32

DK026508-1140

GASKET

SN: 11200-UP

2шт.

33

DK154035-2000

NUT,CAP

SN: 11200-UP

1шт.

34

DK154036-1600

ADAPTER

SN: 11200-UP

1шт.

35

DK139806-0000

BOLT,EYE

SN: 11200-UP

1шт.

36

DK029340-6120

GASKET

SN: 11200-UP

2шт.

37

DK029331-0090

GASKET

SN: 14715-UP

1шт.

|37

DK026510-1340

GASKET

SN: 11200-14714

1шт.
