Запчасти Komatsu 6D140-1A ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|1

6210-71-1111

INJECTION PUMP ASS'Y

SN: 14715-UP

1шт.

|1

0

INJECTION PUMP ASS'Y

SN: 11200-14714

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$4

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK106060-7430

PUMP ASS'Y

SN: 11200-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 AND 0452.

-1шт.

1

DK134062-0620

HOUSING

SN: 11200-UP

1шт.

2

DK029040-6020

STUD

SN: 11200-UP

3шт.

3

DK134311-0000

RING

SN: 11200-UP

1шт.

4

DK134138-0000

STUD

SN: 11200-UP

12шт.

5

DK016650-2230

BEARING

SN: 11200-UP

1шт.

6

DK134303-0400

SHIM¤ 0.60MM

SN: 11200-UP

-2шт.

|6

DK134303-0000

SHIM¤ 1.20MM

SN: 11200-UP

-2шт.

|6

DK134303-0100

SHIM¤ 1.50MM

SN: 11200-UP

-2шт.

|6

DK134303-0200

SHIM¤ 1.80MM

SN: 11200-UP

-2шт.

|6

DK134303-0300

SHIM¤ 2.00MM

SN: 11200-UP

-2шт.

7

DK029010-6810

BOLT

SN: 11200-UP

4шт.

8

DK134371-5000

CAMSHAFT

SN: 11200-UP

1шт.

9

DK134306-0600

BEARING,CENTER

SN: 11200-UP

1шт.

10

DK020106-2040

BOLT

SN: 11200-UP

2шт.

11

DK016650-2230

BEARING

SN: 11200-UP

1шт.

12

DK134316-1700

COVER

SN: 11200-UP

1шт.

13

DK139629-0000

SEAL,OIL

SN: 11200-UP

1шт.

14

DK134314-0000

SHIM¤ 0.10MM

SN: 11200-UP

-2шт.

|14

DK134314-0100

SHIM¤ 0.12MM

SN: 11200-UP

-2шт.

|14

DK134314-0200

SHIM¤ 0.14MM

SN: 11200-UP

-2шт.

|14

DK134314-0300

SHIM¤ 0.16MM

SN: 11200-UP

-2шт.

|14

DK134314-0400

SHIM¤ 0.18MM

SN: 11200-UP

-2шт.

|14

DK134314-0500

SHIM¤ 0.30MM

SN: 11200-UP

-2шт.

|14

DK134314-0600

SHIM¤ 0.50MM

SN: 11200-UP

-2шт.

15

DK029635-5010

O-RING

SN: 11200-UP

1шт.

16

DK134563-0900

SLEEVE

SN: 11200-UP

1шт.

17

DK134045-0100

PLUG

SN: 11200-UP

1шт.

18

DK026524-2940

GASKET

SN: 11200-UP

1шт.

19

DK014110-6440

WASHER,SPRING

SN: 11200-UP

3шт.

20

DK013020-6040

NUT

SN: 11200-UP

3шт.

21

DK131041-0500

GASKET

SN: 11200-UP

1шт.

22

DK134047-0000

PLUG

SN: 11200-UP

6шт.

23

DK025805-1910

KEY

SN: 11200-UP

1шт.

24

DK023641-8410

WASHER,SPRING

SN: 11200-UP

1шт.

25

DK013121-8020

NUT

SN: 11200-UP

1шт.

26

DK156636-6600

COUPLING

SN: 11200-UP

1шт.

27

DK029731-4680

BOLT,EYE

SN: 11200-UP

1шт.

28

DK029341-4130

GASKET

SN: 11200-UP

2шт.

29

DK134442-0720

PIPE

SN: 11200-UP

1шт.

30

DK029731-0490

BOLT,EYE

SN: 11200-UP

1шт.

31

DK029341-0110

GASKET

SN: 11200-UP

3шт.

32

DK131424-3420

VALVE,OVER FLOW

SN: 11200-UP

1шт.

33

DK029341-4130

GASKET

SN: 11200-UP

2шт.

34

DK029731-4680

BOLT,EYE

SN: 11200-UP

1шт.

35

DK029341-4130

GASKET

SN: 11200-UP

2шт.

36

DK134510-8720

BRACKET

SN: 11200-UP

1шт.

37

DK134510-8800

SPACER

SN: 11200-UP

1шт.
