Запчасти Komatsu D670E ГИДРОТРАНСФОРМАТОР ТРАНСМИССИЯ И ЗАДН. МОСТ

1

4400358M91

CONVERTOR

SN: 20183

1шт.

1A

4401720M91

CONVERTOR

SN: 20184-20272

1шт.

1B

4401720M92

CONVERTOR

EnglischBem: REPAIRS AND REPLACES 4401 720 M91

1шт.

|$56

CONVERTOR

DeutschDesc: DREHMOMENTWANDLER

-3шт.

1C

4102606M91

CONVERTOR

SN: 20273-UP

1шт.

|$57

CONVERTOR

DeutschDesc: DREHMOMENTWANDLER

-3шт.

2

339761X1

SCREW

EnglischBem: NOTE: Pos. (2) included in Pos. (1) and (1A) Kit

11шт.

3

2904239M1

DISC

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (1A) Kit

2шт.

4

2904241M1

DISC

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (1A) Kit

5шт.

5

4910172M1

COVER

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (1A) Kit

1шт.

6

3004509X1

SCREW

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (1A) Kit

1шт.

7

2995678X1

O-RING

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (1A) Kit

1шт.

8

4910173M1

RING

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (1A) Kit

1шт.

9

4910174M1

DISC

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (1A) Kit

1шт.

10

4907511M1

DISTANCE PIECE

DeutschDesc: DISTANZSTUECK

1шт.

10A

4918754M1

DISTANCE PIECE

DeutschDesc: DISTANZSTUECK

1шт.

11

4910175M1

BALL BEARING

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (1A) Kit

1шт.

12

4910176M1

SCREW

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (1A) Kit

30шт.

13

4910177M1

COVER

EnglischBem: NOTE: Pos. (13) included in Pos. (1) and (1A) Kit

1шт.

14

1441458X1

CIRCLIP

EnglischBem: NOTE: Pos. (14) included in Pos. (1) and (1A) Kit

1шт.

15

4910178M1

O-RING

EnglischBem: NOTE: Pos. (15) included in Pos. (1) and (1A) Kit

1шт.

16

NOT USED

DeutschDesc: NICHT VERWENDET

-1шт.

17

4910180M1

PISTON

EnglischBem: NOTE: Pos. (17) included in Pos. (1) and (1A) Kit

1шт.

17A

4910181M1

O-RING

EnglischBem: NOTE: Pos. (17A) included in Pos. (1) and (1A) Kit

1шт.

18

4918753M1

INTERNAL DISC

EnglischBem: NOTE: Pos. (18) included in Pos. (1) and (1A) Kit

1шт.

19

2995680X1

O-RING

EnglischBem: NOTE: Pos. (19) included in Pos. (1) and (1A) Kit

1шт.

20

4910183M1

CONVERTER SHELL

EnglischBem: NOTE: Pos. (20) included in Pos. (1) and (1A) Kit

1шт.

21

4910184M1

RING GEAR

EnglischBem: NOTE: Pos. (21) included in Pos. (1) and (1A) Kit

1шт.

22

4910185M1

TURBINE WHEEL

DeutschDesc: TURBINENRAD

1шт.

22A

4918752M1

TURBINE WHEEL

DeutschDesc: TURBINENRAD

1шт.

23

4910186M1

DISC

EnglischBem: NOTE: Pos. (23) included in Pos. (1) and (1A) Kit

12шт.

24

3243141M1

SCREW

EnglischBem: NOTE: Pos. (24) included in Pos. (1) and (1A) Kit

12шт.

25

4910187M1

IDLER

EnglischBem: NOTE: Pos. (25) included in Pos. (1) and (1A) Kit

1шт.

26

3241228M1

CIRCLIP

EnglischBem: NOTE: Pos. (26) included in Pos. (1) and (1A) Kit

1шт.

27

2995766X1

CIRCLIP

EnglischBem: NOTE: Pos. (27) included in Pos. (1) and (1A) Kit

1шт.

28

2995676X1

BALL BEARING

EnglischBem: NOTE: Pos. (28) included in Pos. (1) and (1A) Kit

1шт.

29

2995766X1

CIRCLIP

EnglischBem: NOTE: Pos. (29) included in Pos. (1) and (1A) Kit

1шт.

30

4907515M1

SCREW

EnglischBem: NOTE: Pos. (30) included in Pos. (1) and (1A) Kit

14шт.

31

3002128X1

PLAIN WASHER

EnglischBem: NOTE: Pos. (31) included in Pos. (1) and (1A) Kit

54шт.

32

4910188M1

DISTANCE PIECE

EnglischBem: NOTE: Pos. (32) included in Pos. (1) and (1A) Kit

1шт.

33

4910189M1

SLIDER

EnglischBem: ORDER 4918 755 M1

1шт.

33A

4918755M1

SLIDER

EnglischBem: TO BE INSTALLED TOGETHER NOTE: Pos. (33A) included in Pos. (1) a

1шт.

34

4910190M1

RING

DeutschDesc: RING

2шт.

34A

4918756M1

RING

EnglischBem: TO BE INSTALLED TOGETHER NOTE: Pos. (34A) included in Pos. (1) a

1шт.

34B

4918757M1

RING

EnglischBem: TO BE INSTALLED TOGETHER NOTE: Pos. (34B) included in Pos. (1) a

1шт.

35

2995680X1

O-RING

EnglischBem: NOTE: Pos. (35) included in Pos. (1) and (1A) Kit

1шт.

36

4910191M1

PUMP GEAR

EnglischBem: NOTE: Pos. (36) included in Pos. (1) and (1A) Kit

1шт.

37

4910192M1

SCREW

EnglischBem: NOTE: Pos. (37) included in Pos. (1) and (1A) Kit

10шт.

38

339761X1

SCREW

EnglischBem: NOTE: Pos. (38) included in Pos. (1) and (1A) Kit

30шт.

39

2995678X1

O-RING

EnglischBem: NOTE: Pos. (39) included in Pos. (1) and (1A) Kit

1шт.

40

4910193M1

FLANGE

EnglischBem: NOTE: Pos. (40) included in Pos. (1) and (1A) Kit

1шт.

41

390455X1

CIRCLIP

EnglischBem: NOTE: Pos. (41) included in Pos. (1) and (1A) Kit

1шт.

42

2994734M1

RING

EnglischBem: NOTE: Pos. (42) included in Pos. (1) and (1A) Kit

2шт.

43

4919544M1

CARRIER

EnglischBem: NOTE: Pos. (43) included in Pos. (1) and (1A) Kit

1шт.

43A

4910195M1

CARRIER

DeutschDesc: TRAEGER

1шт.

44

4910194M1

BUSHING

DeutschDesc: BUCHSE

1шт.

45

4911954M1

GASKET

EnglischBem: NOTE: Pos. (45) included in Pos. (1) and (1A) Kit

1шт.
