Запчасти Komatsu D65WX-16 МАРКИРОВКА (№8-) МАРКИРОВКА, АНГЛ., ЕС REGULATION ЧАСТИ КОРПУСА УРОВЕНЬ , ДЛЯ ПОВОРОТН. ОТВАЛА С ИЗМ. УГЛОМ DOZER, ВНУТР. РАМА, MM, ОТВ. С ИЗМ. УГЛОМ POWE

1

09690-F0560

Plate, Komatsu Logo

SN: 80001-UP

1шт.

2

09690-P1120

Plate, Komatsu Logo

SN: 80001-UP

1шт.

3

09690-F0500

Plate, Komatsu Logo

SN: 80001-UP

2шт.

4

09690-M0063

Plate, Komatsu Logo, Anti-Restamp

SN: 80001-80811

1шт.

5

14X-98-11170

Plate, Operating, Lock

SN: 80001-UP

4шт.

6

09602-00001

Plate, Name (Limited Supply)

SN: 80001-UP

1шт.

7

04418-13060

Screw

SN: 80001-UP

4шт.

8

17A-98-11180

Plate, Horn

SN: 80001-UP

1шт.

9

20Y-00-41530

Plate, Symbol, Ecot3

SN: 80001-UP

1шт.

10

09696-50078

Plate, Noise Level, for EU, EU Ope Ear Noise

SN: 80001-UP

1шт.

11

09696-40108

Plate, Noise Level, for EU, EU Around Noise

SN: 80001-UP

1шт.

12

14X-98-35181

Plate, Reflector

SN: 80001-UP

2шт.

13

14X-98-51150

Decal, Machine Model, L.H.

SN: 80001-UP

1шт.

14

14X-98-51250

Decal, Machine Model, R.H.

SN: 80001-UP

1шт.

15

124-98-51140

Plate, Work Equipment

SN: 80001-UP

1шт.

16

14X-98-51221

Oil Chart

SN: 80001-UP

1шт.

17

09653-A0481

Plate, Warning, High Temperature

SN: 80001-UP

1шт.

18

09653-A0481

Plate, Warning, High Temperature

SN: 80001-UP

1шт.

19

09654-B0641

Plate, Warning, Before Leaving Seat

SN: 80001-UP

1шт.

20

09657-A0881

Plate, Warning, Track Adjustment

SN: 80001-UP

2шт.

21

09651-A0641

Plate, Warning, Read Manual Before Operating

SN: 80001-UP

1шт.

22

09802-13000

Plate, Warning, Before Operating and Traveling

SN: 80001-UP

1шт.

23

09806-B1683

Plate, Danger, Keep Away from Machine

SN: 80001-UP

2шт.

24

09667-A0481

Plate, Caution, Rotating Object

SN: 80001-UP

2шт.

25

09963-A1640

Tag, Danger, Do Not Operate

SN: 80001-UP

1шт.

26

09808-A0881

Plate, Warning, Battery Cables

SN: 80001-UP

1шт.

27

09664-60000

Plate, Danger, Battery

SN: 80001-UP

2шт.

28

09659-A057B

Plate, Warning, Explosion Hazard

SN: 80001-UP

1шт.

29

21W-98-41720

Plate, Air Cleaner Replace

SN: 80001-UP

1шт.

30

6217-71-6470

Plate, Fuel Filter Replace

SN: 80001-UP

1шт.

31

14X-98-35120

Plate, Pre Filter Caution

SN: 80001-UP

1шт.

32

09669-0000E

Plate, Symbol, Fuel Filler

SN: 80001-UP

1шт.

33

09649-03012

Plate, Notice, Engine Shutdown

SN: 80001-UP

1шт.

34

09842-A0481

Plate, Warning, No Jump Start

SN: 80001-UP

1шт.

35

09642-13000

Plate, Service Instruction, Engine Coolant AF-NAC

SN: 80001-UP

1шт.
