Запчасти Komatsu D65PX-15E0 КАБИНА (ВОЗД.-CONDITIONER ВОЗДУХОВОДЫ)(№797-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$7

17A-Z11-0046

CAB ASS'Y

SN: 71753-UP

1шт.

|$8

17A-Z11-0045

CAB ASS'Y

SN: 71672-71752

1шт.

|$9

17A-Z11-0044

CAB ASS'Y

SN: 70927-71671

1шт.

|$10

17A-Z11-0065

CAB ASS'Y,(RADIO LESS)

SN: 71753-UP

1шт.

|$11

17A-Z11-0064

CAB ASS'Y,(RADIO LESS)

SN: 70927-71752

1шт.

|$12

17A-Z11-0075

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 71753-UP

1шт.

|$13

17A-Z11-0074

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 70927-71752

1шт.

|$14

17A-Z11-0106

CAB ASS'Y,(AM/FM RADIO)

SN: 71753-UP

1шт.

|$15

17A-Z11-0105

CAB ASS'Y,(AM/FM RADIO)

SN: 71672-71752

1шт.

|$16

17A-Z11-0104

CAB ASS'Y,(AM/FM RADIO)

SN: 70927-71671

1шт.

|$17

17A-Z11-0116

CAB ASS'Y,(FOR USA)

SN: 71753-UP

1шт.

|$18

17A-Z11-0115

CAB ASS'Y,(FOR USA)

SN: 71672-71752

1шт.

|$19

17A-Z11-0114

CAB ASS'Y,(FOR USA)

SN: 70927-71671

1шт.

|$20

17A-Z11-0126

CAB ASS'Y,(EU SILENT SPEC.)

SN: 71753-UP

1шт.

|$21

17A-Z11-0125

CAB ASS'Y,(EU SILENT SPEC.)

SN: 71672-71752

1шт.

|$22

17A-Z11-0124

CAB ASS'Y,(EU SILENT SPEC.)

SN: 70927-71671

1шт.

|$23

17A-Z11-0234

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 71753-UP

1шт.

|$24

17A-Z11-0233

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 71672-71752

1шт.

|$25

17A-Z11-0232

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 70927-71671

1шт.

|$$20

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0A TO K0210-17A0A .

-1шт.

|$28

17A-Z11-3800

DUCT ASS'Y

SN: 69001-UP

1шт.

1

17A-Z11-3811

DUCT

SN: 69001-UP

1шт.

2

17A-Z11-3821

SEAL

SN: 69001-UP

1шт.

3

17A-Z11-3831

SEAL

SN: 69001-UP

1шт.

4

17A-Z11-3781

SHEET

SN: 69001-UP

2шт.

5

17A-Z11-3841

PLATE

SN: 69001-UP

1шт.

6

17A-Z11-3890

BRACKET

SN: 69001-UP

1шт.

7

01245-00835

SCREW

SN: 69001-UP

2шт.

8

01643-70823

WASHER

SN: 69001-UP

8шт.

9

01245-00816

SCREW

SN: 69001-UP

6шт.

10

17A-Z11-3871

DUCT

SN: 69001-UP

1шт.

11

17A-Z11-3881

DUCT

SN: 69001-UP

1шт.

12

01245-00616

SCREW

SN: 69001-UP

8шт.

13

01643-70623

WASHER

SN: 69001-UP

8шт.

14

17A-Z11-7161

LOUVER

SN: 69001-UP

3шт.

15

01370-20316

SCREW

SN: 69992-UP

6шт.

16

17A-Z11-3961

PLATE

SN: 69001-UP

1шт.

17

22U-06-22250

CONVERTER

SN: 69001-UP

1шт.

18

01245-00620

SCREW

SN: 69001-UP

2шт.

19

01643-70623

WASHER

SN: 69001-UP

2шт.
