Запчасти Komatsu D65PX-15 КАБИНА (ДВЕРЬ ФИКСАТОР ОТКРЫТИЯ LATCH) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$7

17A-Z11-0042

CAB ASS'Y

SN: 67207-UP

1шт.

|$8

17A-Z11-0041

CAB ASS'Y

SN: 67150-67206

1шт.

|$9

17A-Z11-0040

CAB ASS'Y

SN: 67001-67149

1шт.

|$10

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: 67207-UP

1шт.

|$11

17A-Z11-0061

CAB ASS'Y,(RADIO LESS)

SN: 67150-67206

1шт.

|$12

17A-Z11-0060

CAB ASS'Y,(RADIO LESS)

SN: 67001-67149

1шт.

|$13

17A-Z11-0072

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67207-UP

1шт.

|$14

17A-Z11-0071

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67150-67206

1шт.

|$15

17A-Z11-0070

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67001-67149

1шт.

|$16

17A-Z11-0102

CAB ASS'Y,(AM/FM RADIO)

SN: 67207-UP

1шт.

|$17

17A-Z11-0101

CAB ASS'Y,(AM/FM RADIO)

SN: 67150-67206

1шт.

|$18

17A-Z11-0100

CAB ASS'Y,(AM/FM RADIO)

SN: 67001-67149

1шт.

|$19

17A-Z11-0112

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67207-UP

1шт.

|$20

17A-Z11-0111

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67150-67206

1шт.

|$21

17A-Z11-0110

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67001-67149

1шт.

|$22

17A-Z11-0122

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67207-UP

1шт.

|$23

17A-Z11-0121

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67150-67206

1шт.

|$24

17A-Z11-0120

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67001-67149

1шт.

|$$19

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

|$26

17A-Z11-0220

CAB ASS'Y

SN: 67827-UP

1шт.

|$$21

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.K0210-01A8 TO K0210-17A8

-1шт.

1

195-Z11-4510

LOCK,R.H.

SN: 67001-UP

1шт.

2

195-Z11-4520

LOCK,L.H.

SN: 67001-UP

1шт.

3

01010-D0635

BOLT

SN: 67001-UP

8шт.

4

01643-70623

WASHER

SN: 67001-UP

8шт.

5

17A-Z11-3463

BRACKET,L.H.

SN: 67001-UP

1шт.

6

17A-Z11-3473

BRACKET,R.H.

SN: 67001-UP

1шт.

7

17A-Z11-1810

BUSHING

SN: 67001-UP

4шт.

8

17A-Z11-3442

RUBBER

SN: 67001-UP

2шт.

9

17A-Z11-3453

RUBBER

SN: 67001-UP

2шт.

10

01010-D1230

BOLT

SN: 67001-UP

4шт.

11

01643-71232

WASHER

SN: 67001-UP

4шт.

12

17A-Z11-3693

PLATE,L.H.

SN: 67001-UP

1шт.

13

17A-Z11-3712

PLATE,R.H.

SN: 67001-UP

1шт.

14

17A-Z11-3914

LEVER

SN: 67150-UP

1шт.

14

17A-Z11-3913

LEVER

SN: 67001-67149

1шт.

15

17A-Z11-3733

LEVER

SN: 67150-UP

1шт.

15

17A-Z11-3732

LEVER

SN: 67001-67149

1шт.

16

17A-Z11-3923

LEVER,L.H.

SN: 67001-UP

1шт.

17

17A-Z11-3722

LEVER,R.H.

SN: 67001-UP

1шт.

18

17A-Z11-3791

SPRING

SN: 67001-UP

2шт.

19

17A-Z11-2820

COVER

SN: 67001-UP

1шт.

20

17A-Z11-2830

COVER

SN: 67001-UP

1шт.

21

01245-00616

SCREW

SN: 67001-UP

8шт.

22

01643-70623

WASHER

SN: 67001-UP

8шт.

23

17A-Z11-3680

PLATE

SN: 67001-UP

2шт.

24

17A-Z11-3483

PLATE

SN: 67001-UP

2шт.

25

01010-80620

BOLT

SN: 67001-UP

2шт.

26

01580-10605

NUT

SN: 67001-UP

2шт.

27

04010-00516

KEY

SN: 67001-UP

2шт.

28

07000-13025

O-RING

SN: 67001-UP

4шт.

29

01010-80830

BOLT

SN: 67001-UP

2шт.

30

01643-70823

WASHER

SN: 67001-UP

2шт.

31

04050-11612

PIN

SN: 67001-UP

2шт.

32

01640-20610

WASHER

SN: 67001-UP

2шт.
