Запчасти Komatsu D65PX-12 МАРКИРОВКА (АНГЛ.) (СЕВ. АМЕРИКА) (ДЛЯ США) (DPX)(№-) МАРКИРОВКА

1

14X-98-11513

OIL CHART

SN: 63398-65000

1шт.

1

14X-98-11512

OIL CHART

SN: 63304-63397

1шт.

2

09651-03001

PLATE, SAFETY,OPERATION AND MAINTENANCE

SN: 63304-@

1шт.

3

09657-03003

PLATE, SAFETY,TRACK ADJUSTMENT

SN: 63304-@

2шт.

4

14X-98-11170

PLATE, OPERATING,LOCK

SN: 63304-@

2шт.

5

14X-98-11560

PLATE,PRESSURE TEST (HSS)

SN: 63304-@

1шт.

6

09690-B0800

PLATE, MARK,KOMATSU, REAR

SN: 63304-@

1шт.

7

09690-B0500

PLATE, MARK,KOMATSU, SIDE

SN: 63304-@

2шт.

8

09690-B0280

PLATE, MARK,KOMATSU, FRONT

SN: 63304-@

1шт.

9

09602-01635

PLATE, NAME,(LIMITED SUPPLY)

SN: 63304-65000

1шт.

10

04418-13060

SCREW

SN: 63304-@

4шт.

11

14X-98-21310

PLATE, MARK,D65PX

SN: 63304-65000

2шт.

12

09664-30068

PLATE, SAFETY,BATTERY (FOR USA)

SN: 63304-@

1шт.

13

14X-98-11370

PLATE, INSTRUCTION,BATTERY HANDLING

SN: 63304-@

2шт.

14

09963-03001

TAG,DO NOT OPERATE

SN: 63304-@

1шт.

15

14X-98-21680

PLATE, MARK,AVANCE

SN: 63304-65000

2шт.

16

14X-98-21780

PLATE, MARK,BOSS

SN: 63304-65000

2шт.

17

09802-13000

PLATE, SAFETY,BEFORE DRIVING

SN: 63304-@

1шт.

18

09653-03001

PLATE, SAFETY,HOT OIL WARNING

SN: 63304-@

1шт.

19

09668-03001

PLATE, SAFETY,HOT WATER WARNING

SN: 63304-@

1шт.

20

09654-33001

PLATE, SAFETY,LEAVING SEAT

SN: 63304-@

1шт.

21

09667-03001

PLATE, SAFETY,REVOLUTION

SN: 63304-@

2шт.

22

09812-13000

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 63304-@

2шт.

23

09808-03000

PLATE, SAFETY,BATTERY CABLE

SN: 63304-@

1шт.

24

14X-98-11230

PLATE, OPERATING,STEERING LEVER (HSS)

SN: 63304-@

1шт.

25

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 63304-@

1шт.

25

14X-98-11270

PLATE, OPERATING,WORK EQUIP.LEVER (PITCH DOZER)

SN: 63304-@

1шт.

25

14X-98-11260

PLATE, OPERATING,WORK EQUIP.LEVER (ANGLE DOZER)

SN: 63304-@

1шт.
