Запчасти Komatsu D65P-12 МАРКИРОВКА (АНГЛ.) (СЕВ. АМЕРИКА) (EXCEPT U.S.A.) (DP)(№-) МАРКИРОВКА

1

14X-98-22711

CHART, OIL

SN: 65001-UP

1шт.

2

09651-03001

PLATE, SAFETY,OPERATION AND MAINTENANCE

SN: 62774-UP

1шт.

3

09657-03003

PLATE, SAFETY,TRACK ADJUSTMENT

SN: 62774-UP

2шт.

4

14X-98-11170

PLATE, OPERATING,LOCK

SN: 60884-UP

2шт.

5

14X-98-11570

PLATE,PRESSURE TEST (C AND B)

SN: 60884-UP

1шт.

6

09690-P1000

PLATE, MARK,KOMATSU, REAR

SN: 65001-UP

1шт.

7

09690-P0560

PLATE, MARK,KOMATSU

SN: 65001-UP

3шт.

8

09690-M0063

PLATE, MARK,KOMATSU

SN: 65001-65787

1шт.

9

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 65579-UP

1шт.

9

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 65001-65578

1шт.

10

04418-13060

SCREW

SN: 60884-UP

4шт.

11

14X-98-23130

PLATE, MARK,D65P, L.H.

SN: 65001-UP

1шт.

12

14X-98-23230

PLATE, MARK,D65P, R.H.

SN: 65001-UP

1шт.

13

14X-98-23160

PLATE, MARK

SN: 65001-UP

1шт.

14

09664-30068

PLATE, SAFETY,BATTERY (FOR USA)

SN: 60884-UP

1шт.

15

14X-98-11370

PLATE, INSTRUCTION,BATTERY HANDLING

SN: 60884-UP

2шт.

16

09963-03001

TAG,DO NOT OPERATE

SN: 63183-UP

1шт.

17

09802-13000

PLATE, SAFETY,BEFORE DRIVING

SN: 62774-UP

1шт.

18

09653-03001

PLATE, SAFETY,HOT OIL WARNING

SN: 62774-UP

1шт.

19

09668-03001

PLATE, SAFETY,HOT WATER WARNING

SN: 62774-UP

1шт.

20

09654-33001

PLATE, SAFETY,LEAVING SEAT

SN: 62774-UP

1шт.

21

09667-03001

PLATE, SAFETY,REVOLUTION

SN: 62774-UP

2шт.

22

09812-13000

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 62774-UP

2шт.

23

09808-03000

PLATE, SAFETY,BATTERY CABLE

SN: 62774-UP

1шт.

23A

09669-0000E

PLATE, CAUTION,FUEL

SN: 65486-UP

1шт.

24

14X-98-11240

PLATE, OPERATING,STEERING LEVER (C AND B)

SN: 60884-UP

1шт.

25

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60884-UP

1шт.

25

14X-98-11270

PLATE, OPERATING,WORK EQUIP.LEVER (PITCH DOZER)

SN: 60884-UP

1шт.

25

14X-98-11260

PLATE, OPERATING,WORK EQUIP.LEVER (ANGLE DOZER)

SN: 60884-UP

1шт.
