Запчасти Komatsu D65P-12 МАРКИРОВКА (АНГЛ.) (DP)(№88-77) МАРКИРОВКА

1

14X-98-11512

OIL CHART

SN: 60933-@

1шт.

1

0

OIL CHART

SN: 60884-60932

1шт.

|$8

14X-98-12310

PLATE

SN: 60884-62773

1шт.

2

0

PLATE, CAUTION,OPERATING OIL TANK

SN: 60884-62773

1шт.

3

0

PLATE, SAFETY,RADIATOR

SN: 60884-62773

1шт.

4

0

PLATE, CAUTION,BEFORE AND AFTER OPERATION

SN: 60884-62773

1шт.

5

0

PLATE, SAFETY,BEFORE OPERATING

SN: 60884-62773

1шт.

6

0

PLATE, CAUTION,SAFETY COMFIRM OF REAR

SN: 60884-62773

1шт.

7

14X-98-11551

PLATE, SAFETY,ADJUSTING TRACK SHOE

SN: 60884-62773

2шт.

8

14X-98-11170

PLATE, OPERATING,LOCK

SN: 60884-@

2шт.

9

14X-98-11570

PLATE,PRESSURE TEST (C AND B)

SN: 60884-@

1шт.

10

09690-C0630

PLATE, MARK,KOMATSU, REAR

SN: 61365-@

1шт.

10

09690-C0400

PLATE, MARK,KOMATSU, REAR

SN: 60884-61364

1шт.

11

09690-B0280

PLATE, MARK,KOMATSU, FRONT

SN: 60884-@

1шт.

12

09602-01635

PLATE, NAME,(LIMITED SUPPLY)

SN: 60884-@

1шт.

12

04418-13060

SCREW

SN: 60884-@

4шт.

13

14X-98-11330

PLATE, MARK,D65P

SN: 60884-@

2шт.

14

14X-98-11240

PLATE, OPERATING,STEERING LEVER (C AND B)

SN: 60884-@

1шт.

15

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60884-@

1шт.

15

14X-98-11260

PLATE, OPERATING,WORK EQUIP.LEVER (ANGLE DOZER)

SN: 60884-@

1шт.

15

14X-98-11270

PLATE, OPERATING,WORK EQUIP.LEVER (PITCH DOZER)

SN: 60884-@

1шт.
