Запчасти Komatsu 6D125-1ZZ ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|1

6150-71-1323

INJECTION PUMP A.

SN: 36135-UP

1шт.

|1

0

INJECTION PUMP A.

SN: 26320-36134

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0455 TO 0483.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND092500-0431

COUPLING ASS'Y

SN: 26320-UP

1шт.

1

ND092415-0610

FLANGE,COUPLING

SN: 26320-UP

1шт.

2

ND092437-0270

COUPLING,CROSS

SN: 26320-UP

1шт.

3

ND092460-0051

PLATE SUB ASS'Y

SN: 26320-UP

2шт.

4

ND949040-6640

BOLT

SN: 26320-UP

2шт.

5

ND949040-6361

BOLT

SN: 26320-UP

6шт.

6

ND092433-0150

BOLT

SN: 26320-UP

1шт.

7

ND092431-0130

NUT

SN: 26320-UP

2шт.

8

ND092551-0430

BLOCK,COUPLING

SN: 26320-UP

1шт.
