Запчасти Komatsu 6D125-1ZZ ТОПЛ. НАСОС (НАСОС) (/) ТОПЛИВН. СИСТЕМА

|1

6150-71-1323

INJECTION PUMP A.

SN: 36135-UP

1шт.

|1

0

INJECTION PUMP A.

SN: 26320-36134

1шт.

|$$3

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0455 TO 0483.

-1шт.

|$$4

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND090100-6091

BODY ASS'Y

SN: 26320-UP

1шт.

|$$6

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 AND 0456.

-1шт.

1

ND090110-3741

HOUSING

SN: 26320-UP

1шт.

2

ND949043-0010

STUD

SN: 26320-UP

3шт.

3

ND949140-3940

O-RING

SN: 26320-UP

1шт.

4

ND090191-1090

CAMSHAFT

SN: 26320-UP

1шт.

5

ND949101-0140

BEARING,ROLLER

SN: 26320-UP

1шт.

6

ND090193-0050

RING,ADJUST

SN: 26320-UP

1шт.

7

ND090194-0070

PLATE¤ 0.1MM

SN: 26320-UP

-2шт.

|7

ND090194-0340

PLATE¤ 0.12MM

SN: 26320-UP

-2шт.

|7

ND090194-0350

PLATE¤ 0.14MM

SN: 26320-UP

-2шт.

|7

ND090194-0080

PLATE¤ 0.15MM

SN: 26320-UP

-2шт.

|7

ND090194-0360

PLATE¤ 0.18MM

SN: 26320-UP

-2шт.

|7

ND090194-0090

PLATE¤ 0.3MM

SN: 26320-UP

-2шт.

|7

ND090194-0100

PLATE¤ 0.5MM

SN: 26320-UP

-2шт.

8

ND949150-1420

SEAL,OIL

SN: 26320-UP

1шт.

9

ND090201-0430

COVER,BEARING

SN: 26320-UP

1шт.

10

ND949047-1380

BOLT

SN: 26320-UP

4шт.

11

ND090433-0020

RETAINER,BEARING

SN: 26320-UP

1шт.

12

ND090361-0100

BEARING,CENTER

SN: 26320-UP

1шт.

13

ND090248-0010

WASHER

SN: 26320-UP

2шт.

14

ND090317-0140

PLUG,SCREW

SN: 26320-UP

1шт.

15

ND090193-0060

RING,ADJUST

SN: 26320-UP

1шт.

16

ND090118-0250

NEEDLE,TIMING

SN: 26320-UP

1шт.

17

ND090222-0070

WASHER

SN: 26320-UP

4шт.

18

ND949180-0310

SCREW

SN: 26320-UP

2шт.

19

ND949140-0380

O-RING

SN: 26320-UP

1шт.

20

ND949101-0130

BEARING,ROLLER

SN: 26320-UP

1шт.

21

ND090194-0300

PLATE¤ 0.1MM

SN: 26320-UP

-2шт.

|21

ND090194-0370

PLATE¤ 0.12MM

SN: 26320-UP

-2шт.

|21

ND090194-0380

PLATE¤ 0.14MM

SN: 26320-UP

-2шт.

|21

ND090194-0310

PLATE¤ 0.16MM

SN: 26320-UP

-2шт.

|21

ND090194-0390

PLATE¤ 0.18MM

SN: 26320-UP

-2шт.

|21

ND090194-0320

PLATE¤ 0.3MM

SN: 26320-UP

-2шт.

|21

ND090194-0330

PLATE¤ 0.5MM

SN: 26320-UP

-2шт.

22

ND949047-0620

BOLT

SN: 26320-UP

2шт.

23

ND949018-0350

WASHER,PLATE

SN: 26320-UP

1шт.

24

ND090012-0140

NUT

SN: 26320-UP

1шт.

25

ND949014-0070

WASHER

SN: 26320-UP

1шт.

26

ND090222-0070

WASHER

SN: 26320-UP

2шт.

27

ND090310-0080

VALVE ASS'Y,OVER FLOW

SN: 26320-UP

1шт.

28

ND90458-05750

KEY

SN: 26320-UP

1шт.
