Запчасти Komatsu D65EX-15E0 КАБИНА (ОМЫВАТЕЛЬ ШЛАНГИ)(№9-79) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$8

17A-Z11-0043

CAB ASS'Y

SN: 69992-70926

1шт.

|$9

17A-Z11-0042

CAB ASS'Y

SN: 69001-69991

1шт.

|$10

17A-Z11-0063

CAB ASS'Y,(RADIO LESS)

SN: 69992-70926

1шт.

|$11

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: 69001-69991

1шт.

|$12

17A-Z11-0073

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 69992-70926

1шт.

|$13

17A-Z11-0072

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 69001-69991

1шт.

|$14

17A-Z11-0103

CAB ASS'Y,(AM/FM RADIO)

SN: 69992-70926

1шт.

|$15

17A-Z11-0102

CAB ASS'Y,(AM/FM RADIO)

SN: 69001-69991

1шт.

|$16

17A-Z11-0113

CAB ASS'Y,(FOR USA)

SN: 69992-70926

1шт.

|$17

17A-Z11-0112

CAB ASS'Y,(FOR USA)

SN: 69001-69991

1шт.

|$18

17A-Z11-0123

CAB ASS'Y,(EU SILENT SPEC.)

SN: 69992-70926

1шт.

|$19

17A-Z11-0122

CAB ASS'Y,(EU SILENT SPEC.)

SN: 69001-69991

1шт.

|$20

17A-Z11-0231

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 69992-70926

1шт.

|$21

17A-Z11-0230

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 69001-69991

1шт.

|$22

17A-Z11-0241

CAB ASS'Y,(FOR FIXED GLASS)

SN: 70107-70926

1шт.

|$$16

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

1

205-06-61220

NOZZLE ASS'Y

SN: 69001-@

1шт.

2

14X-911-3560

BRACKET

SN: 69001-@

1шт.

3

14X-911-3570

PACKING

SN: 69001-@

1шт.

4

01370-00408

SCREW

SN: 69001-@

2шт.

5

17A-Z11-2610

HOSE, 2200MM

SN: 69001-@

1шт.

6

17A-Z11-2620

HOSE, 500MM

SN: 69001-@

1шт.

7

17A-Z11-2630

HOSE, 4000MM

SN: 69001-@

1шт.

8

17A-Z11-2640

HOSE, 3600MM

SN: 69001-@

1шт.

9

14X-911-1130

TUBE

SN: 69001-@

1шт.

10

14X-911-1140

TUBE

SN: 69001-@

1шт.

11

14X-911-1150

TUBE

SN: 69001-@

1шт.

12

17A-Z11-4610

VALVE

SN: 69018-@

3шт.

12

195-979-8590

VALVE

SN: 69001-69017

3шт.

13

17A-Z11-2660

CAP

SN: 69001-@

3шт.
