Запчасти Komatsu D65EX-15E0 КАБИНА (РАМА) (ПРАВ.)(№797-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$8

17A-Z11-0046

CAB ASS'Y

SN: 71753-UP

1шт.

|$9

17A-Z11-0045

CAB ASS'Y

SN: 71672-71752

1шт.

|$10

17A-Z11-0044

CAB ASS'Y

SN: 70927-71671

1шт.

|$11

17A-Z11-0065

CAB ASS'Y,(RADIO LESS)

SN: 71753-UP

1шт.

|$12

17A-Z11-0064

CAB ASS'Y,(RADIO LESS)

SN: 70927-71752

1шт.

|$13

17A-Z11-0075

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 71753-UP

1шт.

|$14

17A-Z11-0074

CAB ASS'Y,(RADIO LESS)(EU SILENT SPEC.)

SN: 70927-71752

1шт.

|$15

17A-Z11-0106

CAB ASS'Y,(AM/FM RADIO)

SN: 71753-UP

1шт.

|$16

17A-Z11-0105

CAB ASS'Y,(AM/FM RADIO)

SN: 71672-71752

1шт.

|$17

17A-Z11-0104

CAB ASS'Y,(AM/FM RADIO)

SN: 70927-71671

1шт.

|$18

17A-Z11-0116

CAB ASS'Y,(FOR USA)

SN: 71753-UP

1шт.

|$19

17A-Z11-0115

CAB ASS'Y,(FOR USA)

SN: 71672-71752

1шт.

|$20

17A-Z11-0114

CAB ASS'Y,(FOR USA)

SN: 70927-71671

1шт.

|$21

17A-Z11-0126

CAB ASS'Y,(EU SILENT SPEC.)

SN: 71753-UP

1шт.

|$22

17A-Z11-0125

CAB ASS'Y,(EU SILENT SPEC.)

SN: 71672-71752

1шт.

|$23

17A-Z11-0124

CAB ASS'Y,(EU SILENT SPEC.)

SN: 70927-71671

1шт.

|$24

17A-Z11-0234

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 71753-UP

1шт.

|$25

17A-Z11-0233

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 71672-71752

1шт.

|$26

17A-Z11-0232

CAB ASS'Y,(FOR EUROPE OR ASIA)

SN: 70927-71671

1шт.

|$$20

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0A TO K0210-17A0A .

-1шт.

|$30

17A-Z11-1401

SASH ASS'Y,R.H.

SN: 69001-UP

1шт.

1

17A-Z11-1410

SASH ASS'Y,R.H.

SN: 69001-UP

1шт.

2

0

FRAME,R.H.

SN: 69001-UP

1шт.

3

17A-Z11-1330

GLASS

SN: 69001-UP

1шт.

4

17A-Z11-1340

SEAL

SN: 69001-UP

1шт.

5

17A-Z11-1350

SEAL

SN: 69001-UP

1шт.

6

17A-Z11-1360

SEAL

SN: 69001-UP

1шт.

7

17A-Z11-1370

SEAL

SN: 69001-UP

1шт.

8

17A-Z11-1480

SEAL

SN: 69001-UP

1шт.

9

17A-Z11-1460

SASH ASS'Y,R.H.

SN: 69001-UP

1шт.

10

0

FRAME,R.H.

SN: 69001-UP

1шт.

11

17A-Z11-1530

GLASS

SN: 69001-UP

1шт.

12

17A-Z11-1540

SEAL

SN: 69001-UP

1шт.

13

17A-Z11-1550

SEAL

SN: 69001-UP

1шт.

14

17A-Z11-1560

SEAL

SN: 69001-UP

1шт.

15

17A-Z11-1570

SEAL

SN: 69001-UP

1шт.

16

17A-Z11-1580

CHANNEL

SN: 69001-UP

1шт.

17

17A-Z11-1490

SHEET

SN: 69001-UP

1шт.

18

17A-Z11-1610

LOCK ASS'Y

SN: 69001-UP

1шт.

19

17A-Z11-1620

STRIKER

SN: 69001-UP

1шт.

20

01252-40514

BOLT

SN: 69001-UP

2шт.

21

01641-50508

WASHER

SN: 69001-UP

2шт.

|$52

195-Z11-1371

LOCK ASS'Y

SN: 69001-UP

2шт.

22

195-Z11-3630

LEVER

SN: 69001-UP

2шт.

23

195-Z11-3640

PLATE

SN: 69001-UP

2шт.

24

195-Z11-3860

PIN

SN: 69001-UP

2шт.

25

195-Z11-3670

SHIM, 0.5MM

SN: 69001-UP

6шт.

26

01252-40514

BOLT

SN: 69001-UP

4шт.

27

01641-50508

WASHER

SN: 69001-UP

4шт.

28

195-Z11-1381

STOPPER

SN: 69001-UP

2шт.

29

01224-70316

SCREW

SN: 71104-UP

4шт.

29

01224-40316

SCREW

SN: 69001-71103

4шт.

30

17A-Z11-1660

PLATE

SN: 69001-UP

2шт.

31

17A-Z11-1391

SEAL

SN: 69001-UP

1шт.

32

17A-Z11-1291

WEATHER STRIP

SN: 69001-UP

2шт.
