Артикул
Название
Примечание
Количество
|1
14X-15-31001
TRANSMISSION ASS'Y
SN: 67137-UP
1шт.
|1
14X-15-31000
TRANSMISSION ASS'Y
SN: 67001-67136
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-62A0.
-1шт.
1
14X-15-22350
CARRIER
SN: 67001-UP
1шт.
3
14X-15-29410
BEARING
SN: 67001-UP
4шт.
5
14X-15-22510
SHAFT
SN: 67001-UP
4шт.
6
14X-15-29210
RING (K2)
SN: 67001-UP
1шт.
8
14X-15-22670
RING GEAR
SN: 67001-UP
1шт.
9
14X-15-29520
SNAP RING
SN: 67001-UP
1шт.
13
14X-15-29220
SEAL RING (K2)
SN: 67001-UP
1шт.
14
14X-15-22440
GEAR
SN: 67001-UP
3шт.
16
14X-15-22520
SHAFT
SN: 67001-UP
3шт.
17
14X-15-12960
PIN
SN: 67001-UP
3шт.
18
14X-15-22430
GEAR
SN: 67001-UP
3шт.
21
14X-15-22530
SHAFT
SN: 67001-UP
3шт.
23
14X-15-29420
BEARING
SN: 67001-UP
3шт.
Выбрано товаров: 27
