Запчасти Komatsu D65EX-15 МАРКИРОВКА (ЯПОН.) (ДЛЯ TОБОД КОЛЕСАMING DOZER) МАРКИРОВКА

1

09690-F0560

PLATE¤ MARK,FRONT

SN: 67001-UP

1шт.

2

09690-P1000

PLATE¤ MARK,REAR

SN: 67001-UP

1шт.

3

09690-P0560

PLATE¤ MARK,SIDE

SN: 67001-UP

2шт.

4

09690-M0063

PLATE¤ MARK,KOMATSU

SN: 67001-UP

1шт.

5

14X-98-32710

OIL CHART

SN: 67001-UP

1шт.

6

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: 67001-UP

2шт.

7

09669-0000E

PLATE¤ CAUTION,FUEL

SN: 67001-UP

1шт.

8

09602-10001

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 67001-UP

1шт.

9

04418-13060

SCREW

SN: 67001-UP

4шт.

10

134-98-31370

PLATE¤ CAUTION,HANDLING POSTURE

SN: 67001-UP

1шт.

11

17A-98-11180

PLATE,HORN

SN: 67001-UP

1шт.

12

14X-98-33120

MARK,D65EX

SN: 67001-UP

1шт.

13

14X-98-33220

MARK,D65EX

SN: 67001-UP

1шт.

14

14X-916-1220

PLATE¤ OPERATING,BLADE TILT

SN: 67001-UP

1шт.

15

09653-A0480

PLATE¤ SAFETY,OPERATING OIL TANK

SN: 67001-UP

1шт.

16

09653-A0480

PLATE¤ SAFETY,RADIATOR

SN: 67001-UP

1шт.

17

09654-B0640

PLATE¤ SAFETY,LEAVING SEAT

SN: 67001-UP

1шт.

18

09657-A0880

PLATE¤ SAFETY,TRACK ADJUSTMENT

SN: 67001-UP

2шт.

19

09651-A0640

PLATE¤ SAFETY,OPERATION AND MAINTENANCE

SN: 67001-UP

1шт.

20

09802-10100

PLATE¤ SAFETY,BEFORE DRIVING

SN: 67001-UP

1шт.

21

09806-B1200

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 67001-UP

2шт.

22

09667-A0480

PLATE¤ SAFETY,REVOLUTION

SN: 67001-UP

2шт.

23

09963-00101

TAG,DO NOT OPERATE

SN: 67001-UP

1шт.

24

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 67001-UP

1шт.

25

14X-98-31180

PLATE,PRESSURE TEST

SN: 67001-UP

1шт.

26

14X-98-31420

PLATE,LABOR SAFETY AND HYGINE LAW

SN: 67001-UP

1шт.

27

203-98-09090

LABEL,SHIFT PATTERN

SN: 67001-UP

1шт.

28

09967-00140

PLATE,EXHAUST GAS

SN: 67001-UP

1шт.
