Запчасти Komatsu D65EX-15 КАБИНА (ОМЫВАТЕЛЬ ШЛАНГИ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

17A-Z11-0040

CAB ASS'Y

SN: 67001-UP

1шт.

|1

17A-Z11-0060

CAB ASS'Y,(RADIO LESS)

SN: 67001-UP

1шт.

|1

17A-Z11-0070

CAB ASS'Y,(RADIO LESS¤ HEAT GLASS)

SN: 67001-UP

1шт.

|1

17A-Z11-0100

CAB ASS'Y,(AM/FM RADIO)

SN: 67001-UP

1шт.

|1

17A-Z11-0110

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67001-UP

1шт.

|1

17A-Z11-0120

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67001-UP

1шт.

|$$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-14A0

-1шт.

1

205-06-61220

NOZZLE ASS'Y

SN: 67001-UP

1шт.

2

14X-911-3560

BRACKET

SN: 67001-UP

1шт.

3

14X-911-3570

PACKING

SN: 67001-UP

1шт.

4

01370-00408

SCREW

SN: 67001-UP

2шт.

5

17A-Z11-2610

HOSE

SN: 67001-UP

1шт.

6

17A-Z11-2620

HOSE

SN: 67001-UP

1шт.

7

17A-Z11-2630

HOSE

SN: 67001-UP

1шт.

8

17A-Z11-2640

HOSE

SN: 67001-UP

1шт.

9

14X-911-1130

TUBE

SN: 67001-UP

1шт.

10

14X-911-1140

TUBE

SN: 67001-UP

1шт.

11

14X-911-1150

TUBE

SN: 67001-UP

1шт.

12

17A-Z11-2650

JOINT

SN: 67001-UP

3шт.

13

17A-Z11-2660

CAP

SN: 67001-UP

3шт.
