Запчасти Komatsu D65EX-15 КАБИНА (ВОЗД.-CONDITIONER ВОЗДУХОВОДЫ)(№7-7) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$6

17A-Z11-0042

CAB ASS'Y

SN: 67192-@

1шт.

|$7

17A-Z11-0041

CAB ASS'Y

SN: 67147-67191

1шт.

|$8

17A-Z11-0040

CAB ASS'Y

SN: 67001-67146

1шт.

|$9

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: 67192-@

1шт.

|$10

17A-Z11-0061

CAB ASS'Y,(RADIO LESS)

SN: 67147-67191

1шт.

|$11

17A-Z11-0060

CAB ASS'Y,(RADIO LESS)

SN: 67001-67146

1шт.

|$12

17A-Z11-0072

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67192-@

1шт.

|$13

17A-Z11-0071

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67147-67191

1шт.

|$14

17A-Z11-0070

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67001-67146

1шт.

|$15

17A-Z11-0102

CAB ASS'Y,(AM/FM RADIO)

SN: 67192-@

1шт.

|$16

17A-Z11-0101

CAB ASS'Y,(AM/FM RADIO)

SN: 67147-67191

1шт.

|$17

17A-Z11-0100

CAB ASS'Y,(AM/FM RADIO)

SN: 67001-67146

1шт.

|$18

17A-Z11-0112

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67192-@

1шт.

|$19

17A-Z11-0111

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67147-67191

1шт.

|$20

17A-Z11-0110

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67001-67146

1шт.

|$21

17A-Z11-0122

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67192-@

1шт.

|$22

17A-Z11-0121

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67147-67191

1шт.

|$23

17A-Z11-0120

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67001-67146

1шт.

|$$19

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

|$26

17A-Z11-3800

DUCT ASS'Y

SN: 67001-@

1шт.

1

17A-Z11-3811

DUCT

SN: 67001-@

1шт.

2

17A-Z11-3821

SEAL

SN: 67001-@

1шт.

3

17A-Z11-3831

SEAL

SN: 67001-@

1шт.

4

17A-Z11-3781

SHEET

SN: 67001-@

2шт.

5

17A-Z11-3841

PLATE

SN: 67001-@

1шт.

6

17A-Z11-3890

BRACKET

SN: 67001-@

1шт.

7

01245-00835

SCREW

SN: 67001-@

2шт.

8

01643-70823

WASHER

SN: 67001-@

8шт.

9

01245-00816

SCREW

SN: 67001-@

6шт.

10

17A-Z11-3871

DUCT

SN: 67001-@

1шт.

11

17A-Z11-3881

DUCT

SN: 67001-@

1шт.

12

01245-00616

SCREW

SN: 67001-@

8шт.

13

01643-70623

WASHER

SN: 67001-@

8шт.

14

17A-Z11-7161

LOUVER

SN: 67001-@

3шт.

15

01370-10312

SCREW

SN: 67001-67312

6шт.

16

17A-Z11-3961

PLATE

SN: 67001-@

1шт.

17

22U-06-22250

CONVERTER

SN: 67001-@

1шт.

18

01245-00620

SCREW

SN: 67001-@

2шт.

19

01643-70623

WASHER

SN: 67001-@

2шт.
