Запчасти Komatsu D65EX-15 КАБИНА (РАМА) (ПРАВ.) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$8

17A-Z11-0042

CAB ASS'Y

SN: 67192-UP

1шт.

|$9

17A-Z11-0041

CAB ASS'Y

SN: 67147-67191

1шт.

|$10

17A-Z11-0040

CAB ASS'Y

SN: 67001-67146

1шт.

|$11

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: 67192-UP

1шт.

|$12

17A-Z11-0061

CAB ASS'Y,(RADIO LESS)

SN: 67147-67191

1шт.

|$13

17A-Z11-0060

CAB ASS'Y,(RADIO LESS)

SN: 67001-67146

1шт.

|$14

17A-Z11-0072

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67192-UP

1шт.

|$15

17A-Z11-0071

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67147-67191

1шт.

|$16

17A-Z11-0070

CAB ASS'Y,(RADIO LESS, HEAT GLASS)

SN: 67001-67146

1шт.

|$17

17A-Z11-0102

CAB ASS'Y,(AM/FM RADIO)

SN: 67192-UP

1шт.

|$18

17A-Z11-0101

CAB ASS'Y,(AM/FM RADIO)

SN: 67147-67191

1шт.

|$19

17A-Z11-0100

CAB ASS'Y,(AM/FM RADIO)

SN: 67001-67146

1шт.

|$20

17A-Z11-0112

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67192-UP

1шт.

|$21

17A-Z11-0111

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67147-67191

1шт.

|$22

17A-Z11-0110

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 67001-67146

1шт.

|$23

17A-Z11-0122

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67192-UP

1шт.

|$24

17A-Z11-0121

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67147-67191

1шт.

|$25

17A-Z11-0120

CAB ASS'Y,(RADIO AM/FM AND CASSETTE)

SN: 67001-67146

1шт.

|$$19

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

|$27

17A-Z11-0221

CAB ASS'Y

SN: 68027-UP

1шт.

|$28

17A-Z11-0220

CAB ASS'Y

SN: 67997-68026

1шт.

|$$22

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A8 TO K0210-17A8.

-1шт.

|$31

17A-Z11-1401

SASH ASS'Y,R.H.

SN: 67001-UP

1шт.

1

17A-Z11-1410

SASH ASS'Y,R.H.

SN: 67001-UP

1шт.

2

0

FRAME,R.H.

SN: 67001-UP

1шт.

3

17A-Z11-1330

GLASS

SN: 67001-UP

1шт.

4

17A-Z11-1340

SEAL

SN: 67001-UP

1шт.

5

17A-Z11-1350

SEAL

SN: 67001-UP

1шт.

6

17A-Z11-1360

SEAL

SN: 67001-UP

1шт.

7

17A-Z11-1370

SEAL

SN: 67001-UP

1шт.

8

17A-Z11-1480

SEAL

SN: 67001-UP

1шт.

9

17A-Z11-1460

SASH ASS'Y,R.H.

SN: 67001-UP

1шт.

10

0

FRAME,R.H.

SN: 67001-UP

1шт.

11

17A-Z11-1530

GLASS

SN: 67001-UP

1шт.

12

17A-Z11-1540

SEAL

SN: 67001-UP

1шт.

13

17A-Z11-1550

SEAL

SN: 67001-UP

1шт.

14

17A-Z11-1560

SEAL

SN: 67001-UP

1шт.

15

17A-Z11-1570

SEAL

SN: 67001-UP

1шт.

16

17A-Z11-1580

CHANNEL

SN: 67001-UP

1шт.

17

17A-Z11-1490

SHEET

SN: 67001-UP

1шт.

18

17A-Z11-1610

LOCK ASS'Y

SN: 67001-UP

1шт.

19

17A-Z11-1620

STRIKER

SN: 67001-UP

1шт.

20

01252-40514

BOLT

SN: 67001-UP

2шт.

21

01641-50508

WASHER

SN: 67001-UP

2шт.

|$53

195-Z11-1371

LOCK ASS'Y

SN: 67001-UP

2шт.

22

195-Z11-3630

LEVER

SN: 67001-UP

2шт.

23

195-Z11-3640

PLATE

SN: 67001-UP

2шт.

24

195-Z11-3860

PIN

SN: 67001-UP

2шт.

25

195-Z11-3670

SHIM, 0.5MM

SN: 67001-UP

6шт.

26

01252-40514

BOLT

SN: 67001-UP

4шт.

27

01641-50508

WASHER

SN: 67001-UP

4шт.

28

195-Z11-1381

STOPPER

SN: 67001-UP

2шт.

29

01224-40316

SCREW

SN: 67001-UP

4шт.

30

17A-Z11-1660

PLATE

SN: 67001-UP

2шт.

31

17A-Z11-1391

SEAL

SN: 67001-UP

1шт.

32

17A-Z11-1291

WEATHER STRIP

SN: 67001-UP

2шт.
