Запчасти Komatsu D65EX-12U МАРКИРОВКА (АНГЛ.) (СЕВ. АМЕРИКА) (EXCEPT U.S.A.) (DEX(№97-) МАРКИРОВКА

1

14X-98-11513

OIL CHART

SN: 63503-65000

1шт.

1

14X-98-11512

OIL CHART

SN: 60942-63502

1шт.

2

09651-03001

PLATE, SAFETY,OPERATION AND MAINTENANCE

SN: 62967-@

1шт.

3

09657-03003

PLATE, SAFETY,TRACK ADJUSTMENT

SN: 62967-@

2шт.

4

14X-98-11170

PLATE, OPERATING,LOCK

SN: 60942-@

2шт.

5

14X-98-11560

PLATE,PRESSURE TEST (HSS)

SN: 60942-@

1шт.

6

09690-C0630

PLATE, MARK,KOMATSU, REAR

SN: 60942-65000

1шт.

7

09690-B0280

PLATE, MARK,KOMATSU, FRONT

SN: 60942-65000

1шт.

8

09602-01635

PLATE, NAME,(LIMITED SUPPLY)

SN: 60942-65000

1шт.

9

04418-13060

SCREW

SN: 60942-@

4шт.

10

14X-98-11320

PLATE, MARK,D65EX

SN: 60942-65000

2шт.

11

09664-30068

PLATE, SAFETY,BATTERY (FOR USA)

SN: 60942-@

1шт.

12

14X-98-11370

PLATE, INSTRUCTION,BATTERY HANDLING

SN: 60942-@

2шт.

13

09963-03001

TAG,DO NOT OPERATE

SN: 63228-@

1шт.

13

09963-03000

TAG,DO NOT OPERATE

SN: 60942-63227

1шт.

14

17A-98-16110

PLATE, MARK,AVANCE

SN: 60942-@

2шт.

15

09802-13000

PLATE, SAFETY,BEFORE DRIVING

SN: 62967-@

1шт.

16

09653-03001

PLATE, SAFETY,HOT OIL WARNING

SN: 62967-@

1шт.

17

09668-03001

PLATE, SAFETY,HOT WATER WARNING

SN: 62967-@

1шт.

18

09654-33001

PLATE, SAFETY,LEAVING SEAT

SN: 62967-@

1шт.

19

09667-03001

PLATE, SAFETY,REVOLUTION

SN: 62967-@

2шт.

20

09812-13000

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 62967-@

2шт.

21

09808-03000

PLATE, SAFETY,BATTERY CABLE

SN: 62967-@

1шт.

22

14X-98-11230

PLATE, OPERATING,STEERING LEVER (HSS)

SN: 60942-@

1шт.

23

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60942-@

1шт.

23

14X-98-11260

PLATE, OPERATING,WORK EQUIP.LEVER (ANGLE DOZER)

SN: 60942-@

1шт.

23

14X-916-1220

PLATE, OPERATING,WORK EQUIP.LEVER (TRIMMING D.)

SN: 60942-@

1шт.
