Запчасти Komatsu D65EX-12U МАРКИРОВКА (АНГЛ.) (DEX)(№97-) МАРКИРОВКА

1

14X-98-11513

OIL CHART

SN: 63395-65000

1шт.

1

14X-98-11512

OIL CHART

SN: 60954-63394

1шт.

2

09651-A0641

PLATE, SAFETY,OPERATION AND MAINTENANCE

SN: 62967-@

1шт.

3

09657-A0881

PLATE, SAFETY,TRACK ADJUSTMENT

SN: 62967-@

2шт.

4

14X-98-11170

PLATE, OPERATING,LOCK

SN: 60942-@

2шт.

5

14X-98-11560

PLATE,PRESSURE TEST (HSS)

SN: 60942-@

1шт.

6

09690-C0630

PLATE, MARK,KOMATSU, REAR

SN: 61446-65000

1шт.

7

09690-B0280

PLATE, MARK,KOMATSU, FRONT

SN: 60942-@

1шт.

8

09602-01635

PLATE, NAME,(LIMITED SUPPLY)

SN: 60942-@

1шт.

9

04418-13060

SCREW

SN: 60942-@

4шт.

10

14X-98-11320

PLATE, MARK,D65EX

SN: 60942-65000

2шт.

11

09802-B0750

PLATE, SAFETY,BEFORE DRIVING

SN: 62967-@

1шт.

12

09653-A0481

PLATE, SAFETY,HOT OIL/WATER WARNING

SN: 62967-@

2шт.

13

09654-B0641

PLATE, SAFETY,LEAVING SEAT

SN: 62967-@

1шт.

14

09667-A0481

PLATE, SAFETY,REVOLUTION

SN: 62967-@

2шт.

15

09806-B1201

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 62967-@

2шт.

16

09808-A0881

PLATE, SAFETY,BATTERY CABLE

SN: 62967-@

1шт.

17

09963-A1640

TAG,DO NOT OPERATE

SN: 62967-@

1шт.

18

14X-98-11230

PLATE, OPERATING,STEERING LEVER (HSS)

SN: 60942-UP

1шт.

19

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60942-UP

1шт.

19

14X-98-11260

PLATE, OPERATING,WORK EQUIP.LEVER (ANGLE DOZER)

SN: 60942-UP

1шт.

19

14X-916-1220

PLATE, OPERATING,WORK EQUIP.LEVER (TRIMMING D.)

SN: 60942-UP

1шт.
