Запчасти Komatsu D65EX-12 КАБИНА (ЗАДН. РАБОЧ. ОСВЕЩЕНИЕ)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$6

14X-Z11-0020

CAB ASS'Y,(AM RADIO, F.R. WORK LAMP)

SN: 65001-UP

1шт.

|$7

14X-Z11-0030

CAB ASS'Y,(AM/FM CST.ST., F.R.WORK LAMP)

SN: 65001-UP

1шт.

|$8

14X-Z11-0060

CAB ASS'Y,(AM RADIO, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$9

14X-Z11-0070

CAB ASS'Y,(AM/FM CT.ST, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$10

14X-Z11-0080

CAB ASS'Y,(RADIO LESS, F.R. WORK LAMP)

SN: 65001-UP

1шт.

|$11

14X-Z11-0100

CAB ASS'Y,(RADIO LESS, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$$7

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-6241

BRACKET

SN: 65001-UP

2шт.

2

14X-06-11120

WORKING LAMP ASS'Y,60W

SN: 65001-UP

2шт.

3

01582-11411

NUT

SN: 65001-UP

1шт.

4

01643-31445

WASHER

SN: 65001-UP

1шт.

5

14X-911-6331

WIRE ASS'Y

SN: 65001-UP

1шт.

6

21W-54-14690

CLIP

SN: 65001-UP

5шт.

7

08036-11214

CLIP

SN: 65001-UP

2шт.

8

14X-911-3710

SWITCH,FRONT WORK LAMP

SN: 65001-UP

1шт.
