Запчасти Komatsu D65EX-12 КАБИНА (ДВОРНИКИ)(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$13

14X-911-0810

CAB ASS'Y,(AM RADIO)

SN: 60942-65000

1шт.

|$14

14X-911-0820

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 60942-65000

1шт.

|$15

14X-911-0830

CAB ASS'Y,(AM RADIO, F.R. WORK LAMP)

SN: 60942-65000

1шт.

|$16

14X-911-0840

CAB ASS'Y,(AM/FM CST.ST., F.R.WORK LAMP)

SN: 60942-65000

1шт.

|$17

14X-911-0850

CAB ASS'Y,(AM RADIO, FRONT WORK LAMP)

SN: 60942-65000

1шт.

|$18

14X-911-0860

CAB ASS'Y,(AM/FM CT.ST, FRONT WORK LAMP)

SN: 60942-65000

1шт.

|$19

14X-911-0870

CAB ASS'Y,(AM RADIO, REAR WORK LAMP)

SN: 60942-65000

1шт.

|$20

14X-911-0880

CAB ASS'Y,(AM/FM CT.ST, REAR WORK LAMP)

SN: 60942-65000

1шт.

|$21

14X-911-0890

CAB ASS'Y,(RADIO LESS)

SN: 60942-65000

1шт.

|$22

14X-911-0900

CAB ASS'Y,(RADIO LESS, F.R. WORK LAMP)

SN: 60942-65000

1шт.

|$23

14X-911-0910

CAB ASS'Y,(RADIO LESS, FRONT WORK LAMP)

SN: 60942-65000

1шт.

|$24

14X-911-0920

CAB ASS'Y,(RADIO LESS, REAR WORK LAMP)

SN: 60942-65000

1шт.

|$25

14X-911-0980

CAB ASS'Y,(TRIMMING)

SN: 60942-65000

1шт.

|$$14

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-3111

WIPER MOTOR ASS'Y,FRONT

SN: 60942-65000

1шт.

2

01435-20612

BOLT

SN: 60942-65000

4шт.

3

14X-911-3210

ARM,WIPER

SN: 60942-65000

1шт.

3

ND857059-0020

SCREW

SN: 60942-65000

1шт.

3

ND857056-1540

NUT

SN: 60942-65000

1шт.

4

14X-911-3310

BLADE,WIPER

SN: 60942-65000

1шт.

5

14X-911-3120

WIPER MOTOR ASS'Y,L.H.

SN: 60942-65000

1шт.

5

14X-911-3130

WIPER MOTOR ASS'Y,R.H.

SN: 60942-65000

1шт.

6

14X-911-3221

ARM,WIPER

SN: 60942-65000

2шт.

7

14X-911-3321

BLADE,WIPER

SN: 60942-65000

2шт.

8

14X-911-3411

BRACKET,L.H.

SN: 60942-65000

1шт.

8

14X-911-3421

BRACKET,R.H.

SN: 60942-65000

1шт.

9

01435-01016

BOLT

SN: 60942-65000

4шт.

10

14X-911-3141

WIPER MOTOR ASS'Y,REAR

SN: 60942-65000

1шт.

11

14X-911-3241

ARM,WIPER

SN: 60942-65000

1шт.

12

14X-911-3330

BLADE,WIPER

SN: 60942-65000

1шт.

13

01023-10512

SCREW

SN: 60942-65000

2шт.

14

205-06-61220

NOZZLE ASS'Y

SN: 60942-65000

4шт.

15

14X-911-3560

BRACKET

SN: 60942-65000

4шт.

16

01370-00408

SCREW

SN: 60942-65000

8шт.

17

14X-911-3570

PACKING

SN: 60942-65000

2шт.

18

14X-911-3531

HOSE, 1500MM,L.H.

SN: 60942-65000

1шт.

18

14X-911-3541

HOSE, 4550MM,R.H.

SN: 60942-65000

1шт.

19

14X-911-3611

HOSE, 2800MM

SN: 60942-65000

1шт.

20

14X-911-3621

HOSE, 3350MM

SN: 60942-65000

1шт.

21

08051-00801

CLIP

SN: 60942-65000

10шт.

22

14X-911-1130

TUBE

SN: 60942-65000

1шт.

23

14X-911-1140

TUBE

SN: 60942-65000

1шт.

24

14X-911-1150

TUBE

SN: 60942-65000

1шт.

25

08210-00401

SPIRAL TUBE,SPIRAL

SN: 60942-65000

2шт.
