Запчасти Komatsu D65EX-12 КАБИНА (РАМА И РУЧКА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|$14

14X-Z11-0010

CAB ASS'Y,(AM RADIO)

SN: 65001-UP

1шт.

|$15

14X-911-0080

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 65001-UP

1шт.

|$16

14X-Z11-0020

CAB ASS'Y,(AM RADIO, F.R. WORK LAMP)

SN: 65001-UP

1шт.

|$17

14X-Z11-0030

CAB ASS'Y,(AM/FM CST.ST., F.R.WORK LAMP)

SN: 65001-UP

1шт.

|$18

14X-Z11-0040

CAB ASS'Y,(AM RADIO, FRONT WORK LAMP)

SN: 65001-UP

1шт.

|$19

14X-Z11-0050

CAB ASS'Y,(AM/FM CT.ST, FRONT WORK LAMP)

SN: 65001-UP

1шт.

|$20

14X-Z11-0060

CAB ASS'Y,(AM RADIO, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$21

14X-Z11-0070

CAB ASS'Y,(AM/FM CT.ST, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$22

14X-911-0070

CAB ASS'Y,(RADIO LESS)

SN: 65001-UP

1шт.

|$23

14X-Z11-0080

CAB ASS'Y,(RADIO LESS, F.R. WORK LAMP)

SN: 65001-UP

1шт.

|$24

14X-Z11-0090

CAB ASS'Y,(RADIO LESS, FRONT WORK LAMP)

SN: 65001-UP

1шт.

|$25

14X-Z11-0100

CAB ASS'Y,(RADIO LESS, REAR WORK LAMP)

SN: 65001-UP

1шт.

|$26

14X-911-0060

CAB ASS'Y,(FOR RADIO LESS)(EXCEPT JAPAN)

SN: 65001-UP

1шт.

|$27

14X-911-0730

CAB ASS'Y,(FOR TRIMMING)

SN: 65001-UP

1шт.

|$$15

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-2211

GLASS,FRONT

SN: 65001-UP

1шт.

2

14X-911-2291

SPACER

SN: 65001-UP

1шт.

3

14X-911-2241

GLASS,REAR

SN: 65001-UP

1шт.

4

14X-911-2311

STRIP,WEATHER

SN: 65001-UP

1шт.

5

14X-911-2221

GLASS,DOOR

SN: 65001-UP

2шт.

6

14X-911-2321

STRIP,WEATHER

SN: 65001-UP

2шт.

7

198-Z11-2260

SEAL (BONDED)

SN: 65001-UP

1шт.

|$39

14X-911-2113

SASH ASS'Y,L.H.

SN: 65001-UP

1шт.

|$40

14X-911-2613

SASH ASS'Y,R.H.

SN: 65001-UP

1шт.

8

14X-911-6610

FRAME,L.H.

SN: 65001-UP

1шт.

8

14X-911-6780

FRAME,R.H.

SN: 65001-UP

1шт.

9

14X-911-6620

GLASS,UPPER

SN: 65001-UP

1шт.

10

14X-911-6630

GLASS,REAR

SN: 65001-UP

1шт.

11

14X-911-6640

GLASS,FRONT

SN: 65001-UP

1шт.

12

14X-911-6650

SEAL,L.H.

SN: 65001-UP

1шт.

12

14X-911-6790

SEAL,R.H.

SN: 65001-UP

1шт.

13

14X-911-6660

SEAL,INSIDE

SN: 65001-UP

1шт.

14

14X-911-6670

SEAL

SN: 65001-UP

1шт.

15

14X-911-6680

SEAL,INSIDE

SN: 65001-UP

1шт.

16

20Y-54-13322

LOCK ASS'Y

SN: 65001-UP

1шт.

17

14X-911-6710

STOPPER

SN: 65001-UP

2шт.

18

01224-40316

SCREW

SN: 65001-UP

4шт.

19

14X-911-6720

FRAME,REAR GLASS

SN: 65001-UP

1шт.

20

14X-911-6730

SEAL,REAR GLASS

SN: 65001-UP

1шт.

21

14X-911-6740

SEAL,FRONT GLASS

SN: 65001-UP

1шт.

22

14X-911-6750

STOPPER

SN: 65001-UP

2шт.

23

14X-911-6760

SEAL,OUTER

SN: 65001-UP

1шт.

24

14X-911-6770

FRAME,FRONT GLASS

SN: 65001-UP

1шт.

|$60

14X-911-0090

BRACKET ASS'Y

SN: 65001-UP

1шт.

25

14X-911-2620

BRACKET,OUTER

SN: 65001-UP

1шт.

26

14X-911-2630

BRACKET,INNER

SN: 65001-UP

1шт.

27

14X-911-2650

SEAL

SN: 65001-UP

2шт.

28

14X-911-2661

LEVER ASS'Y

SN: 65001-UP

1шт.

29

14X-911-2670

BLOCK

SN: 65001-UP

1шт.

30

14X-911-2640

CUSHION

SN: 65001-UP

2шт.

31

14X-911-2680

SEAT

SN: 65001-UP

4шт.

32

20Y-54-13180

SEAT

SN: 65001-UP

6шт.

33

20Y-54-13180

SEAT

SN: 65001-UP

20шт.

34

14X-911-2350

TRIM

SN: 65001-UP

2шт.

35

361-54-21150

HANDLE

SN: 65001-UP

2шт.

36

01220-40820

SCREW

SN: 65001-UP

4шт.

37

14X-911-5521

GRIP

SN: 65001-UP

2шт.

38

01435-30816

BOLT

SN: 65001-UP

4шт.

39

361-54-21150

HANDLE

SN: 65001-UP

2шт.

40

01220-40820

SCREW

SN: 65001-UP

4шт.
