Запчасти Komatsu D65E-12 МАРКИРОВКА (ФРАНЦИЯ) (EXCEPT FRANCE) (DE)(№9-9) МАРКИРОВКА

1

14X-98-11612

OIL CHART

SN: 60942-@

1шт.

2

14X-98-11620

PLATE, SAFETY,OPERATING OIL TANK

SN: 60942-62966

1шт.

3

14X-98-11630

PLATE, SAFETY,RADIATOR

SN: 60942-62966

1шт.

4

14X-98-11640

PLATE, CAUTION,BEFORE AND AFTER OPERATION

SN: 60942-62966

1шт.

5

14X-98-11650

PLATE, SAFETY,ADJUSTING TRACK SHOE

SN: 60942-62966

2шт.

6

14X-98-11170

PLATE, OPERATING,LOCK

SN: 60942-@

2шт.

7

14X-98-11670

PLATE,PRESSURE TEST (C AND B)

SN: 60942-@

1шт.

8

09690-C0630

PLATE, MARK,KOMATSU, REAR

SN: 61446-@

1шт.

8

09690-C0400

PLATE, MARK,KOMATSU, REAR

SN: 60942-61445

1шт.

9

09690-B0280

PLATE, MARK,KOMATSU, FRONT

SN: 60942-@

1шт.

10

09602-51635

PLATE, NAME,(LIMITED SUPPLY)

SN: 62376-@

1шт.

10

09602-52635

PLATE, NAME,(LIMITED SUPPLY)

SN: 60942-62375

1шт.

10

04418-13060

SCREW

SN: 60942-@

4шт.

11

14X-98-11340

PLATE, MARK,D65E

SN: 60942-@

2шт.

12

17A-98-11660

PLATE, CAUTION,SAFETY COMFIRM OF REAR

SN: 60942-@

1шт.

13

17A-98-11640

PLATE, CAUTION,KEEP A SAFE DISTANCE

SN: 60942-@

2шт.

14

14X-98-11240

PLATE, OPERATING,STEERING LEVER (C AND B)

SN: 60942-@

1шт.

15

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60942-@

1шт.
