Запчасти Komatsu D65E-12-E КАБИНА (КРЫША ABSORBER И ОТДЕЛКА)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

14X-Z11-0010

CAB ASS'Y,(AM RADIO)

SN: 65001-UP

1шт.

|1

14X-911-0080

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 65001-UP

1шт.

|1

14X-Z11-0020

CAB ASS'Y,(AM RADIO¤ F.R. WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0030

CAB ASS'Y,(AM/FM CST.ST.¤ F.R.WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0040

CAB ASS'Y,(AM RADIO¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0050

CAB ASS'Y,(AM/FM CT.ST¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0060

CAB ASS'Y,(AM RADIO¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0070

CAB ASS'Y,(AM/FM CT.ST¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-911-0070

CAB ASS'Y,(RADIO LESS)

SN: 65001-UP

1шт.

|1

14X-Z11-0080

CAB ASS'Y,(RADIO LESS¤ F.R. WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0090

CAB ASS'Y,(RADIO LESS¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0100

CAB ASS'Y,(RADIO LESS¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-911-0060

CAB ASS'Y,(FOR RADIO LESS)(EXCEPT JAPAN)

SN: 65001-UP

1шт.

|$$14

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-5631

ABSORBER

SN: 65001-UP

1шт.

2

14X-911-5641

ABSORBER

SN: 65001-UP

1шт.

3

14X-911-5750

ABSORBER

SN: 65001-UP

2шт.

4

14X-911-5651

ABSORBER

SN: 65001-UP

1шт.

5

14X-911-5730

ABSORBER

SN: 65001-UP

1шт.

6

14X-911-5310

RIVET

SN: 65001-UP

2шт.

7

14X-911-5661

BRACKET

SN: 65001-UP

1шт.

8

01435-20612

BOLT

SN: 65001-UP

4шт.

9

20Y-54-18690

RIVET

SN: 65001-UP

7шт.

10

14X-911-5540

SPACER

SN: 65001-UP

1шт.

11

14X-911-5141

GARNISH,L.H.

SN: 65001-UP

1шт.

12

14X-911-5151

GARNISH,R.H.

SN: 65001-UP

1шт.

13

14X-911-5181

GARNISH,L.H.

SN: 65001-UP

1шт.

14

14X-911-5191

GARNISH,R.H.

SN: 65001-UP

1шт.

15

14X-911-5211

GARNISH,L.H.

SN: 65001-UP

1шт.

16

14X-911-5222

GARNISH,R.H.

SN: 65001-UP

1шт.

17

14X-911-5231

GARNISH

SN: 65001-UP

1шт.

18

01435-00820

BOLT

SN: 65190-UP

2шт.

|18

01435-30820

BOLT

SN: 65001-65189

2шт.

19

20Y-54-18690

RIVET

SN: 65001-UP

12шт.

20

14X-911-3431

COVER,L.H.

SN: 65001-UP

1шт.

21

14X-911-3441

COVER,R.H.

SN: 65001-UP

1шт.

22

14X-911-1770

SCREW

SN: 65001-UP

8шт.

23

14X-911-5412

POCKET,L.H.

SN: 65001-UP

1шт.

24

14X-911-5422

POCKET,R.H.

SN: 65001-UP

1шт.

25

14X-911-5430

CLIP

SN: 65001-UP

6шт.
