Запчасти Komatsu D65E-12-E КАБИНА (ДВЕРЬ И ЗАМОК ДВЕРИ)(№-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

14X-Z11-0010

CAB ASS'Y,(AM RADIO)

SN: 65001-UP

1шт.

|1

14X-911-0080

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 65001-UP

1шт.

|1

14X-Z11-0020

CAB ASS'Y,(AM RADIO¤ F.R. WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0030

CAB ASS'Y,(AM/FM CST.ST.¤ F.R.WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0040

CAB ASS'Y,(AM RADIO¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0050

CAB ASS'Y,(AM/FM CT.ST¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0060

CAB ASS'Y,(AM RADIO¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0070

CAB ASS'Y,(AM/FM CT.ST¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-911-0070

CAB ASS'Y,(RADIO LESS)

SN: 65001-UP

1шт.

|1

14X-Z11-0080

CAB ASS'Y,(RADIO LESS¤ F.R. WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0090

CAB ASS'Y,(RADIO LESS¤ FRONT WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-Z11-0100

CAB ASS'Y,(RADIO LESS¤ REAR WORK LAMP)

SN: 65001-UP

1шт.

|1

14X-911-0060

CAB ASS'Y,(FOR RADIO LESS)(EXCEPT JAPAN)

SN: 65001-UP

1шт.

|$$14

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-1323

DOOR,L.H.

SN: 65001-UP

1шт.

|1

14X-911-1423

DOOR,R.H.

SN: 65001-UP

1шт.

2

14X-911-1390

SEAL

SN: 65001-UP

2шт.

3A

14X-911-1430

SEAL,L.H.

SN: 65399-UP

1шт.

|3A

14X-911-1440

SEAL,R.H.

SN: 65399-UP

1шт.

3B

14X-911-1450

SEAL,L.H.

SN: 65399-UP

1шт.

|3B

14X-911-1460

SEAL,R.H.

SN: 65399-UP

1шт.

3

14X-911-5310

RIVET

SN: 65001-UP

4шт.

4

14X-911-1330

HINGE

SN: 65001-UP

6шт.

5

01435-01025

BOLT

SN: 65001-UP

36шт.

6

195-Z11-4510

LOCK,L.H.

SN: 65001-UP

1шт.

|6

195-Z11-4520

LOCK,R.H.

SN: 65001-UP

1шт.

7

01010-80635

BOLT

SN: 65001-UP

8шт.

8

01602-20619

WASHER

SN: 65001-UP

8шт.

9

14X-911-1631

STRIKER

SN: 65001-UP

2шт.

10

01643-31232

WASHER

SN: 65001-UP

2шт.

11

198-Z11-3710

HANDLE ASS'Y

SN: 65001-UP

2шт.

12

01023-10520

SCREW

SN: 65001-UP

10шт.

13

14X-911-1721

PLATE

SN: 65001-UP

2шт.

14

23S-06-14990

SCREW

SN: 65001-UP

6шт.

15

362-06-21140

WASHER

SN: 65001-UP

6шт.

16

14X-911-1941

LEVER,L.H.

SN: 65001-UP

1шт.

|16

14X-911-1951

LEVER,R.H.

SN: 65001-UP

1шт.

17

14X-911-1643

PLATE,L.H.

SN: 65001-UP

1шт.

|17

14X-911-1653

PLATE,R.H.

SN: 65001-UP

1шт.

18

04205-10614

PIN

SN: 65001-UP

4шт.

19

01641-20608

WASHER

SN: 65001-UP

4шт.

20

04050-11612

PIN

SN: 65001-UP

4шт.

21

14X-911-1540

KNOB

SN: 65001-UP

2шт.

22

176-06-42170

SPRING

SN: 65001-UP

2шт.

23

14X-911-1712

COVER

SN: 65001-UP

6шт.

24

01023-20512

SCREW

SN: 65001-UP

4шт.

25

14X-911-1780

SEAL

SN: 65001-UP

2шт.

26

04205-10622

PIN

SN: 65001-UP

2шт.

27

01643-10623

WASHER

SN: 65001-UP

8шт.

28

04052-10633

PIN

SN: 65001-UP

2шт.

29

14X-911-2341

TRIM

SN: 65001-UP

2шт.

30

14X-911-5831

PLATE

SN: 65001-UP

2шт.

31

01023-20616

SCREW

SN: 65001-UP

6шт.

32

14X-911-1690

DUMPER

SN: 65001-UP

4шт.

33

14X-911-1761

SHIM¤ 1.2MM

SN: 65001-UP

8шт.

34

01023-20616

SCREW

SN: 65001-UP

8шт.
