Запчасти Komatsu D65E-12-E КОРПУС КАБИНЫ(№9-) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

14X-911-0810

CAB ASS'Y,(AM RADIO)

SN: 60942-65000

1шт.

|1

14X-911-0820

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 60942-65000

1шт.

|1

14X-911-0830

CAB ASS'Y,(AM RADIO¤ F.R. WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0840

CAB ASS'Y,(AM/FM CST.ST.¤ F.R.WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0850

CAB ASS'Y,(AM RADIO¤ FRONT WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0860

CAB ASS'Y,(AM/FM CT.ST¤ FRONT WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0870

CAB ASS'Y,(AM RADIO¤ REAR WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0880

CAB ASS'Y,(AM/FM CT.ST¤ REAR WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0890

CAB ASS'Y,(RADIO LESS)

SN: 60942-65000

1шт.

|1

14X-911-0900

CAB ASS'Y,(RADIO LESS¤ F.R. WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0910

CAB ASS'Y,(RADIO LESS¤ FRONT WORK LAMP)

SN: 60942-65000

1шт.

|1

14X-911-0920

CAB ASS'Y,(RADIO LESS¤ REAR WORK LAMP)

SN: 60942-65000

1шт.

|$$13

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-1111

CAB

SN: 60942-65000

1шт.

2

01010-81220

BOLT

SN: 60942-65000

12шт.

3

01643-31232

WASHER

SN: 60942-65000

12шт.

4

14X-911-1191

PLATE

SN: 60942-65000

4шт.

5

14X-911-5671

BRACKET

SN: 60942-65000

1шт.

6

01010-81225

BOLT

SN: 60942-65000

3шт.

7

01643-31232

WASHER

SN: 60942-65000

3шт.

8

14X-911-2541

COVER,L.H.

SN: 60942-65000

1шт.

9

14X-911-2551

COVER,R.H.

SN: 60942-65000

1шт.

10

01435-31016

BOLT

SN: 60942-65000

6шт.

11

14X-911-5711

BRACKET,L.H.

SN: 60942-65000

1шт.

12

14X-911-5721

BRACKET,R.H.

SN: 60942-65000

1шт.

13

203-43-56450

CAP¤ PEDAL

SN: 60942-65000

2шт.

14

01439-01225

BOLT

SN: 60942-65000

4шт.
