Запчасти Komatsu D61PX-15E0-BW ГУСЕНИЧНАЯ РАМА ХОДОВАЯ

1

13G-30-71111

FRAME, L.H.

SN: B45001-UP

1шт.

2

134-30-61C50

PLATE (WELDED)

SN: B45001-UP

4шт.

3

134-30-61C60

PLATE (WELDED)

SN: B45001-UP

2шт.

4

134-30-64231

GUARD, L.H. (FRONT OUTER) (WELDED)

SN: B45001-UP

1шт.

5

134-30-64241

GUARD, L.H. (FRONT INNER) (WELDED)

SN: B45001-UP

1шт.

6

14Y-30-11227

BRACKET (WELDED)

SN: B45001-UP

1шт.

7

134-30-74270

BRACKET (WELDED)

SN: B45001-UP

1шт.

8

134-50-61140

BUSHING

SN: B45001-UP

1шт.

9

134-50-61150

BUSHING

SN: B45001-UP

1шт.

10

13G-30-71121

FRAME, R.H.

SN: B45001-UP

1шт.

11

134-30-61C50

PLATE (WELDED)

SN: B45001-UP

4шт.

12

134-30-61C60

PLATE (WELDED)

SN: B45001-UP

2шт.

13

134-30-64231

GUARD, R.H. (FRONT INNER) (WELDED)

SN: B45001-UP

1шт.

14

134-30-64241

GUARD, R.H. (FRONT OUTER) (WELDED)

SN: B45001-UP

1шт.

15

14Y-30-11227

BRACKET (WELDED)

SN: B45001-UP

1шт.

16

134-30-74270

BRACKET (WELDED)

SN: B45001-UP

1шт.

17

134-50-61140

BUSHING

SN: B45001-UP

1шт.

18

134-50-61150

BUSHING

SN: B45001-UP

1шт.

19

14Y-30-11277

COVER

SN: B45001-UP

2шт.

20

01010-81225

BOLT

SN: B45001-UP

4шт.

21

01643-31232

WASHER

SN: B45001-UP

4шт.

22

07049-01215

PLUG

SN: B45001-UP

24шт.

23

07049-01620

PLUG

SN: B45001-UP

20шт.
