Запчасти Komatsu D61PX-15E0-BW КАБИНА (ВОЗД.-CONDITIONER ВОЗДУХОВОДЫ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

17A-Z11-0064

CAB ASS'Y,(RADIO LESS)

SN: B45850-UP

1шт.

|1

17A-Z11-0063

CAB ASS'Y,(RADIO LESS)

SN: B45207-B45849

1шт.

|1

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: B45001-B45206

1шт.

|1

17A-Z11-0072

CAB ASS'Y,(RADIO LESS¤ HEAT GLASS)

SN: B45001-UP

1шт.

|1

17A-Z11-0112

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: B45001-UP

1шт.

|1

17A-Z11-0122

CAB ASS'Y,(RADIO CASSETTE¤ HEAT GLASS)

SN: B45001-UP

1шт.

|$34

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

|1

17A-Z11-3800

DUCT ASS'Y

SN: B45001-UP

1шт.

1

0

DUCT

SN: B45001-UP

1шт.

2

17A-Z11-3821

SEAL

SN: B45001-UP

1шт.

3

17A-Z11-3831

SEAL

SN: B45001-UP

1шт.

4

17A-Z11-3781

SHEET

SN: B45001-UP

2шт.

5

17A-Z11-3841

PLATE

SN: B45001-UP

1шт.

6

17A-Z11-3890

BRACKET

SN: B45001-UP

1шт.

7

01245-00835

SCREW

SN: B45001-UP

2шт.

8

01643-70823

WASHER

SN: B45001-UP

8шт.

9

01245-00816

SCREW

SN: B45001-UP

6шт.

10

17A-Z11-3871

DUCT

SN: B45001-UP

1шт.

11

17A-Z11-3881

DUCT

SN: B45001-UP

1шт.

12

01245-00616

SCREW

SN: B45001-UP

8шт.

13

01643-70623

WASHER

SN: B45001-UP

8шт.

14

17A-Z11-7161

LOUVER

SN: B45001-UP

3шт.

15

01370-20316

SCREW

SN: B45001-UP

2шт.

16

01370-20316

SCREW

SN: B45001-UP

4шт.

17

17A-Z11-3961

PLATE

SN: B45001-UP

1шт.

18

22U-06-22250

CONVERTER

SN: B45001-UP

1шт.

19

01245-00620

SCREW

SN: B45001-UP

2шт.

20

01643-70623

WASHER

SN: B45001-UP

2шт.
