Артикул
Название
Примечание
Количество
|1
17A-Z11-0064
CAB ASS'Y,(RADIO LESS)
SN: B45850-UP
1шт.
|1
17A-Z11-0063
CAB ASS'Y,(RADIO LESS)
SN: B45207-B45849
1шт.
|1
17A-Z11-0062
CAB ASS'Y,(RADIO LESS)
SN: B45001-B45206
1шт.
|1
17A-Z11-0072
CAB ASS'Y,(RADIO LESS¤ HEAT GLASS)
SN: B45001-UP
1шт.
|1
17A-Z11-0112
CAB ASS'Y,(AM/FM CASSETTE STEREO)
SN: B45001-UP
1шт.
|1
17A-Z11-0122
CAB ASS'Y,(RADIO CASSETTE¤ HEAT GLASS)
SN: B45001-UP
1шт.
|$43
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.
-1шт.
|1
17A-Z11-1401
SASH ASS'Y
SN: B45001-UP
1шт.
|1
17A-Z11-1410
SASH ASS'Y
SN: B45001-UP
1шт.
1
0
FRAME
SN: B45001-UP
1шт.
2
17A-Z11-1330
GLASS
SN: B45001-UP
1шт.
3
17A-Z11-1340
SEAL
SN: B45001-UP
1шт.
4
17A-Z11-1350
SEAL
SN: B45001-UP
1шт.
5
17A-Z11-1360
SEAL
SN: B45001-UP
1шт.
6
17A-Z11-1370
SEAL
SN: B45001-UP
1шт.
7
17A-Z11-1480
SEAL
SN: B45001-UP
1шт.
|8
17A-Z11-1460
SASH ASS'Y
SN: B45001-UP
1шт.
8
0
FRAME
SN: B45001-UP
1шт.
9
17A-Z11-1530
GLASS
SN: B45001-UP
1шт.
10
17A-Z11-1540
SEAL
SN: B45001-UP
1шт.
11
17A-Z11-1550
SEAL
SN: B45001-UP
1шт.
12
17A-Z11-1560
SEAL
SN: B45001-UP
1шт.
13
17A-Z11-1570
SEAL
SN: B45001-UP
1шт.
14
17A-Z11-1580
CHANNEL
SN: B45001-UP
1шт.
15
17A-Z11-1490
SHEET
SN: B45001-UP
1шт.
16
17A-Z11-1610
LOCK ASS'Y
SN: B45001-UP
1шт.
17
17A-Z11-1620
STRIKER
SN: B45001-UP
1шт.
19
01641-50508
WASHER
SN: B45001-UP
2шт.
|20
195-Z11-1371
LOCK ASS'Y
SN: B45001-UP
2шт.
20
195-Z11-3630
LEVER
SN: B45001-UP
2шт.
21
195-Z11-3640
PLATE
SN: B45001-UP
2шт.
22
195-Z11-3860
PIN
SN: B45001-UP
2шт.
23
195-Z11-3670
SHIM¤ 0.5MM
SN: B45001-UP
6шт.
25
01641-50508
WASHER
SN: B45001-UP
4шт.
26
195-Z11-1381
STOPPER
SN: B45001-UP
2шт.
27
01224-70316
SCREW
SN: B45001-UP
4шт.
28
17A-Z11-1660
PLATE
SN: B45001-UP
2шт.
29
17A-Z11-1391
SEAL
SN: B45001-UP
1шт.
Выбрано товаров: 40
