Запчасти Komatsu D61PX-15 КЛАПАН PPC(ДЛЯ PAT) (/) Y [РЕМ. КОМПЛЕКТЫ И COMPONENTS ЧАСТИ]

|1

702-16-01992

PILOT VALVE

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS. Y1670-01A0 TO Y1670 04A0.

SN: B40001-UP

-1шт.

1

0

VALVE

SN: B40001-UP

2шт.

2

702-16-51140

SHIM, 0.30MM

SN: B40001-UP

2шт.

3

702-16-59630

SPRING

SN: B40001-UP

1шт.

4

0

SPRING

SN: B40001-UP

1шт.

5

702-16-53530

RETAINER

SN: B40001-UP

1шт.

6

702-16-57310

RETAINER

SN: B40001-UP

1шт.

7

702-16-53160

SPRING

SN: B40001-UP

1шт.

8

702-16-55630

SPRING

SN: B40001-UP

1шт.

9

702-16-51270

SEAL

SN: B40001-UP

2шт.

10

07000-12020

O-RING

SN: B40001-UP

1шт.

11

0

PISTON

SN: B40001-UP

2шт.

12

702-16-55491

SPRING

SN: B40001-UP

1шт.

13

702-16-55530

COLLAR

SN: B40001-UP

1шт.

14

702-16-55540

SPRING

SN: B40001-UP

1шт.

15

702-16-55550

SHIM

SN: B40001-UP

2шт.

16

702-16-55560

RETAINER

SN: B40001-UP

1шт.

17

702-16-55570

COLLAR

SN: B40001-UP

1шт.

18

702-16-55580

SPACER

SN: B40001-UP

4шт.

19

702-16-55590

BALL

SN: B40001-UP

13шт.

20

702-21-38460

O-RING

SN: B40001-UP

4шт.

21

0

PISTON

SN: B40001-UP

1шт.

22

0

ROD

SN: B40001-UP

2шт.

23

0

PISTON

SN: B40001-UP

1шт.

24

0

BUSHING

SN: B40001-UP

1шт.
