Запчасти Komatsu D61PX-15 ГИДР. НАСОС. (СИЛОВАЯ ЛИНИЯ) (/) Y [РЕМ. КОМПЛЕКТЫ И COMPONENTS ЧАСТИ]

|1

705-51-20840

PUMP ASSEMBLY, (SAL40+40)

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1610-11A0 AND Y1610-12A0.

-1шт.

|1

705-11-32240

PUMP ASSEMBLY, (SAL40)

SN: B40001-UP

1шт.

1

0

BRACKET ASSEMBLY

SN: B40001-UP

1шт.

|1

0

BUSHING

SN: B40001-UP

2шт.

2

0

CASE, GEAR

SN: B40001-UP

1шт.

3

0

CARRIER ASSEMBLY

SN: B40001-UP

1шт.

|4

0

BUSHING

SN: B40001-UP

2шт.

4

0

GEAR, DRIVE

SN: B40001-UP

1шт.

5

0

GEAR, DRIVEN

SN: B40001-UP

1шт.

6

705-17-02612

PLATE, SIDE

SN: B40001-UP

2шт.

7

705-17-02430

RING, BACK-UP

SN: B40001-UP

2шт.

8

705-17-02460

RING, SEAL

SN: B40001-UP

2шт.

9

705-17-02360

O-RING

SN: B40001-UP

2шт.

10

04020-01024

PIN, DOWEL

SN: B40001-UP

4шт.

11

01253-61205

BOLT

SN: B40001-UP

4шт.

12

01643-51232

WASHER

SN: B40001-UP

4шт.

13

705-17-02870

PLATE

SN: B40001-UP

1шт.

14

705-17-02830

SEAL, OIL

SN: B40001-UP

1шт.

15

04065-04018

RING, SNAP

SN: B40001-UP

1шт.

16

705-17-02330

COUPLING ASSEMBLY

SN: B40001-UP

1шт.
