Запчасти Komatsu D61PX-15 НАСОС ВЕНТИЛЯТОРА (/) Y [РЕМ. КОМПЛЕКТЫ И COMPONENTS ЧАСТИ]

|1

708-1S-00240

PUMP ASSEMBLY

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-11A0 TO Y1600-15A0.

-1шт.

|1

708-1S-01930

PUMP SUB ASSEMBLY

SN: B40001-UP

1шт.

1

0

SHAFT

SN: B40001-UP

1шт.

2

0

BEARING

SN: B40001-UP

1шт.

3

0

BEARING

SN: B40001-UP

1шт.

4

0

SPACER KIT

SN: B40001-UP

1шт.

5

0

RING, WIRE

SN: B40001-UP

1шт.

6

0

RETAINER

SN: B40001-UP

1шт.

7

708-1S-12340

CASE

SN: B40001-UP

1шт.

8

708-1T-11880

SEAL, OIL

SN: B40001-UP

1шт.

9

207-09-11140

O-RING

SN: B40001-UP

1шт.

10

04065-06220

RING

SN: B40001-UP

1шт.

11

0

BLOCK, CYLINDER

SN: B40001-UP

1шт.

12

0

PLATE, VALVE

SN: B40001-UP

1шт.

13

0

WASHER

SN: B40001-UP

2шт.

14

0

SPRING

SN: B40001-UP

1шт.

15

0

RING, SNAP

SN: B40001-UP

1шт.

16

0

GUIDE, RETAINER

SN: B40001-UP

1шт.

17

0

PIN

SN: B40001-UP

3шт.

18

0

RETAINER, SHOE

SN: B40001-UP

1шт.

19

0

PISTON SUB ASSEMBLY

SN: B40001-UP

7шт.

20

0

PLUG

SN: B40001-UP

1шт.

21

0

PLUG

SN: B40001-UP

1шт.

22

0

O-RING

SN: B40001-UP

2шт.

23

0

PISTON SUB ASSEMBLY

SN: B40001-UP

1шт.

24

0

SPRING

SN: B40001-UP

1шт.
