Запчасти Komatsu D61PX-15 КАБИНА (ОМЫВАТЕЛЬ ШЛАНГИ) K [КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ]

|1

17A-Z11-0042

CAB ASSEMBLY

SN: B40001-UP

1шт.

|1

17A-Z11-0062

CAB ASSEMBLY, (RADIO LESS)

SN: B40001-UP

1шт.

|1

17A-Z11-0072

CAB ASSEMBLY, (RADIO LESS, HEAT GLASS)

SN: B40001-UP

1шт.

|1

17A-Z11-0102

CAB ASSEMBLY, (AM/FM RADIO)

SN: B40001-UP

1шт.

|1

17A-Z11-0112

CAB ASSEMBLY, (AM/FM CASSETTE STEREO)

SN: B40001-UP

1шт.

|1

17A-Z11-0122

CAB ASSEMBLY, (RADIO AM/FM AND CASSETTE)

SN: B40001-UP

1шт.

|$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210

-1шт.

1

205-06-61220

NOZZLE ASSEMBLY

SN: B40001-UP

1шт.

2

14X-911-3560

BRACKET

SN: B40001-UP

1шт.

3

14X-911-3570

PACKING

SN: B40001-UP

1шт.

4

01370-00408

SCREW

SN: B40001-UP

2шт.

5

17A-Z11-2610

HOSE

SN: B40001-UP

1шт.

6

17A-Z11-2620

HOSE

SN: B40001-UP

1шт.

7

17A-Z11-2630

HOSE

SN: B40001-UP

1шт.

8

17A-Z11-2640

HOSE

SN: B40001-UP

1шт.

9

14X-911-1130

TUBE

SN: B40001-UP

1шт.

10

14X-911-1140

TUBE

SN: B40001-UP

1шт.

11

14X-911-1150

TUBE

SN: B40001-UP

1шт.

12

195-979-8590

VALVE

SN: B40001-UP

3шт.

13

17A-Z11-2660

CAP

SN: B40001-UP

3шт.
