Запчасти Komatsu D61PX-15 КАБИНА (РАМА) (ЛЕВ.) K [КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ]

|1

17A-Z11-0042

CAB ASSEMBLY

SN: B40001-UP

1шт.

|1

17A-Z11-0062

CAB ASSEMBLY, (RADIO LESS)

SN: B40001-UP

1шт.

|1

17A-Z11-0072

CAB ASSEMBLY, (RADIO LESS, HEAT GLASS)

SN: B40001-UP

1шт.

|1

17A-Z11-0102

CAB ASSEMBLY, (AM/FM RADIO)

SN: B40001-UP

1шт.

|1

17A-Z11-0112

CAB ASSEMBLY, (AM/FM CASSETTE STEREO)

SN: B40001-UP

1шт.

|1

17A-Z11-0122

CAB ASSEMBLY, (RADIO AM/FM AND CASSETTE)

SN: B40001-UP

1шт.

|$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210

-1шт.

|1

17A-Z11-1301

SASH ASSEMBLY, L.H.

SN: B40001-UP

1шт.

|1

17A-Z11-1310

SASH ASSEMBLY, L.H.

SN: B40001-UP

1шт.

1

0

FRAME, L.H.

SN: B40001-UP

1шт.

2

17A-Z11-1330

GLASS

SN: B40001-UP

1шт.

3

17A-Z11-1340

SEAL

SN: B40001-UP

1шт.

4

17A-Z11-1350

SEAL

SN: B40001-UP

1шт.

5

17A-Z11-1360

SEAL

SN: B40001-UP

1шт.

6

17A-Z11-1370

SEAL

SN: B40001-UP

1шт.

7

17A-Z11-1480

SEAL

SN: B40001-UP

1шт.

|8

17A-Z11-1510

SASH ASSEMBLY, L.H.

SN: B40001-UP

1шт.

8

0

FRAME, L.H.

SN: B40001-UP

1шт.

9

17A-Z11-1530

GLASS

SN: B40001-UP

1шт.

10

17A-Z11-1540

SEAL

SN: B40001-UP

1шт.

11

17A-Z11-1550

SEAL

SN: B40001-UP

1шт.

12

17A-Z11-1560

SEAL

SN: B40001-UP

1шт.

13

17A-Z11-1570

SEAL

SN: B40001-UP

1шт.

14

17A-Z11-1580

CHANNEL

SN: B40001-UP

1шт.

15

17A-Z11-1490

SHEET

SN: B40001-UP

1шт.

16

17A-Z11-1610

LOCK ASSEMBLY

SN: B40001-UP

1шт.

17

17A-Z11-1620

STRIKER

SN: B40001-UP

1шт.

18

01225-40514

SCREW

SN: B40001-UP

2шт.

19

01640-50508

WASHER

SN: B40001-UP

2шт.

|20

195-Z11-1371

LOCK ASSEMBLY

SN: B40001-UP

2шт.

20

195-Z11-3630

LEVER

SN: B40001-UP

2шт.

21

195-Z11-3640

PLATE

SN: B40001-UP

2шт.

22

195-Z11-3860

PIN

SN: B40001-UP

2шт.

23

195-Z11-3670

SHIM, 0.5MM

SN: B40001-UP

6шт.

24

01252-40514

BOLT

SN: B40001-UP

4шт.

25

01640-50508

WASHER

SN: B40001-UP

4шт.

26

195-Z11-1381

STOPPER

SN: B40001-UP

2шт.

27

01224-40316

SCREW

SN: B40001-UP

4шт.

28

17A-Z11-1660

PLATE

SN: B40001-UP

2шт.

29

17A-Z11-1391

SEAL

SN: B40001-UP

1шт.
