Артикул
Название
Примечание
Количество
|1
134-15-71000
TRANSMISSION ASSEMBLY
SN: B40001-UP
1шт.
|$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.F2320-51A0 TO F2320-62A0.
-1шт.
1
14X-15-21150
HOUSING
SN: B40001-UP
1шт.
3
14X-15-22750
PISTON
SN: B40001-UP
1шт.
9
14X-15-22640
RING GEAR
SN: B40001-UP
1шт.
10
14X-15-22780
PLATE
SN: B40001-UP
5шт.
11
14X-15-22710
DISC
SN: B40001-UP
4шт.
12
14X-15-21160
HOUSING
SN: B40001-UP
1шт.
17
14X-15-29220
SEAL RING (K2)
SN: B40001-UP
1шт.
19
14X-15-22661
RING GEAR
SN: B40001-UP
1шт.
20
14X-15-22780
PLATE
SN: B40001-UP
8шт.
21
14X-15-22710
DISC
SN: B40001-UP
7шт.
25
14X-15-21170
HOUSING
SN: B40001-UP
1шт.
29
14X-15-22740
PISTON
SN: B40001-UP
1шт.
31
14X-15-22770
PISTON
SN: B40001-UP
1шт.
33
14X-15-12910
SPRING
SN: B40001-UP
5шт.
35
14X-15-22780
PLATE
SN: B40001-UP
6шт.
36
14X-15-22710
DISC
SN: B40001-UP
5шт.
37
14X-15-21180
HOUSING
SN: B40001-UP
1шт.
39
14X-15-29230
SEAL RING (K2)
SN: B40001-UP
1шт.
40
145-14-11571
WASHER
SN: B40001-UP
14шт.
41
144-15-21191
BOLT
SN: B40001-UP
3шт.
43
14X-15-22371
COVER
SN: B40561-UP
1шт.
43
14X-15-22370
COVER
SN: B40001-B40560
1шт.
44
14X-15-29230
SEAL RING (K2)
SN: B40001-UP
1шт.
Выбрано товаров: 50
