Запчасти Komatsu D61PX-12 МАРКИРОВКА (ЯПОН.) (DPX) МАРКИРОВКА

1

13G-98-61110

PLATE¤ MARK,D61PX

SN: 1001-UP

2шт.

2

09690-B0224

PLATE¤ MARK,KOMATSU¤ FRONT

SN: 1001-UP

1шт.

3

09690-C0400

PLATE¤ MARK,KOMATSU¤ REAR

SN: 1001-UP

1шт.

4

134-98-61211

OIL CHART

SN: 1224-UP

1шт.

|4

134-98-61210

OIL CHART

SN: 1001-1223

1шт.

5

09602-10000

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 1001-UP

1шт.

|5

04418-13060

SCREW

SN: 1001-UP

4шт.

6

13G-98-61130

PLATE,LABOR SAFETY AND HYGINE LAW

SN: 1001-UP

1шт.

7

124-98-51140

PLATE¤ OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: 1001-UP

1шт.

|7

14X-98-11250

PLATE¤ OPERATING,WORK EQUIP.LEVER (ST.TILT D.)

SN: 1001-UP

1шт.

7A

134-54-66190

PLATE,PROTECTION FILM

SN: 1189-UP

1шт.

7B

134-54-66290

PLATE,PROTECTION FILM

SN: 1189-UP

1шт.

8

14X-98-11230

PLATE¤ OPERATING,STEERING LEVER (HSS)

SN: 1001-UP

1шт.

9

134-98-61320

PLATE,PRESSURE TEST (HSS)

SN: 1001-UP

1шт.

10

09653-A0480

PLATE¤ SAFETY,CAUTION OIL AND WATER

SN: 1001-UP

2шт.

11

09657-A0880

PLATE¤ SAFETY,ADJUSTING TRACK TENSION

SN: 1001-UP

2шт.

12

09651-A0640

PLATE¤ SAFETY,READ OPERATION MANUAL

SN: 1001-UP

1шт.

13

09802-10100

PLATE¤ SAFETY,SAFETY IN REAR

SN: 1001-UP

1шт.

14

09654-B0640

PLATE¤ SAFETY,CAUTION AFTER OPERATING

SN: 1001-UP

1шт.

15

17A-98-11180

PLATE,HORN

SN: 1001-UP

1шт.

16

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: 1001-UP

2шт.

17

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: 1001-UP

1шт.

18

09963-00101

TAG,DO NOT OPERATE

SN: 1001-UP

1шт.

19

09806-B1200

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 1001-UP

2шт.

20

09667-A0640

PLATE¤ SAFETY,REVOLVING OBJECT CAUTION

SN: 1001-UP

2шт.

21

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 1001-UP

1шт.

22

134-98-61190

PLATE,EMISSIONIZED ENGINE

SN: 1001-UP

1шт.

23

134-98-31370

PLATE¤ CAUTION,MACHINE SLING POSITION

SN: 1001-UP

1шт.

24

09669-0000E

PLATE¤ CAUTION,DIESEL FUEL

SN: 1225-UP

1шт.
