Запчасти Komatsu D61PX-12 МАРКИРОВКА (PORTUGAL) (DPX) МАРКИРОВКА

1

13G-98-61110

PLATE, MARK,D61PX

SN: 1001-UP

2шт.

2

09690-B0224

PLATE, MARK,KOMATSU, FRONT

SN: 1001-UP

1шт.

3

09690-C0800

PLATE, MARK,KOMATSU, REAR

SN: 1001-UP

1шт.

4

134-98-61212

OIL CHART

SN: 1233-UP

1шт.

4

134-98-61211

OIL CHART

SN: 1224-1232

1шт.

4

134-98-61210

OIL CHART

SN: 1001-1223

1шт.

5

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 1238-UP

1шт.

5

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 1001-1237

1шт.

5

0

PLATE,(LIMITED SUPPLY)

SN: 1001-UP

1шт.

5

04418-13060

SCREW

SN: 1001-UP

4шт.

6

124-98-51140

PLATE, OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: 1001-UP

1шт.

6

14X-98-11250

PLATE, OPERATING,WORK EQUIP.LEVER (ST.TILT D.)

SN: 1001-UP

1шт.

7

134-54-66190

PLATE,PROTECTION FILM

SN: 1189-UP

1шт.

8

134-54-66290

PLATE,PROTECTION FILM

SN: 1189-UP

1шт.

9

14X-98-11230

PLATE, OPERATING,STEERING LEVER (HSS)

SN: 1001-UP

1шт.

10

134-98-61370

PLATE,PRESSURE TEST (HSS)

SN: 1001-UP

1шт.

11

09653-07001

PLATE, SAFETY,CAUTION OIL

SN: 1001-UP

1шт.

12

09668-07001

PLATE, SAFETY,CAUTION WATER

SN: 1001-UP

1шт.

13

09657-07002

PLATE, SAFETY,ADJUSTING TRACK TENSION

SN: 1001-UP

2шт.

14

09651-07001

PLATE, SAFETY,READ OPERATION MANUAL

SN: 1001-UP

1шт.

15

09802-17000

PLATE, SAFETY,SAFETY IN REAR

SN: 1001-UP

1шт.

16

09654-37001

PLATE, SAFETY,CAUTION AFTER OPERATING

SN: 1001-UP

1шт.

17

17A-98-11180

PLATE,HORN

SN: 1001-UP

1шт.

18

14X-98-11170

PLATE, OPERATING,LOCK

SN: 1001-UP

2шт.

19

09637-50263

PLATE, INSTRUCTION,AIR CLEANER

SN: 1001-UP

1шт.

20

09963-07001

TAG,DO NOT OPERATE

SN: 1001-UP

1шт.

21

09812-17000

PLATE, SAFETY,DANGER, KEEP A SAFE DISTANCE

SN: 1001-UP

2шт.

22

09667-07001

PLATE, SAFETY,REVOLVING OBJECT CAUTION

SN: 1001-UP

2шт.

23

09808-07000

PLATE, SAFETY,BATTERY CABLE

SN: 1001-UP

1шт.

24

134-98-31370

PLATE, CAUTION,MACHINE SLING POSITION

SN: 1001-1251

1шт.

25

09669-0000E

PLATE, CAUTION,DIESEL FUEL

SN: 1225-UP

1шт.
