Запчасти Komatsu D61EX-15E0-BW КАБИНА (ОМЫВАТЕЛЬ ШЛАНГИ) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

17A-Z11-0064

CAB ASS'Y,(RADIO LESS)

SN: B45850-UP

1шт.

|1

17A-Z11-0063

CAB ASS'Y,(RADIO LESS)

SN: B45207-B45849

1шт.

|1

17A-Z11-0062

CAB ASS'Y,(RADIO LESS)

SN: B45001-B45206

1шт.

|1

17A-Z11-0072

CAB ASS'Y,(RADIO LESS¤ HEAT GLASS)

SN: B45001-UP

1шт.

|1

17A-Z11-0112

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: B45001-UP

1шт.

|1

17A-Z11-0122

CAB ASS'Y,(RADIO CASSETTE¤ HEAT GLASS)

SN: B45001-UP

1шт.

|$24

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210-01A0 TO K0210-17A0.

-1шт.

1

205-06-61220

NOZZLE ASS'Y

SN: B45001-UP

1шт.

2

14X-911-3560

BRACKET

SN: B45001-UP

1шт.

3

14X-911-3570

PACKING

SN: B45001-UP

1шт.

4

01370-00408

SCREW

SN: B45001-UP

2шт.

5

17A-Z11-2610

HOSE¤ 2200MM

SN: B45001-UP

1шт.

6

17A-Z11-2620

HOSE¤ 500MM

SN: B45001-UP

1шт.

7

17A-Z11-2630

HOSE¤ 4000MM

SN: B45001-UP

1шт.

8

17A-Z11-2640

HOSE¤ 3600MM

SN: B45001-UP

1шт.

9

14X-911-1130

TUBE

SN: B45001-UP

1шт.

10

14X-911-1140

TUBE

SN: B45001-UP

1шт.

11

14X-911-1150

TUBE

SN: B45001-UP

1шт.

12

17A-Z11-4610

VALVE

SN: B45001-UP

3шт.

13

17A-Z11-2660

CAP

SN: B45001-UP

3шт.
