Запчасти Komatsu D61EX-15 ГЕНЕРАТОР (A) Y [ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|$1

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

600-861-6110

ALTERNATOR A.(60A)

SN: B40001-UP

1шт.

1

KD0-35100-0300

ROTOR ASSEMBLY

SN: B40001-UP

1шт.

2

KD1-33923-0790

COLLAR

SN: B40001-UP

1шт.

3

KD1-35923-0160

COLLAR

SN: B40001-UP

1шт.

4

KD0-09201-0980

BEARING, BALL

SN: B40001-UP

1шт.

5

KD0-35200-0460

STATOR ASSEMBLY

SN: B40001-UP

1шт.

6

KD0-35300-0350

FRONT BRACKET ASSEMBLY

SN: B40001-UP

1шт.

7

KD0-09201-1140

BEARING, BALL

SN: B40001-UP

1шт.

8

KD0-35926-0070

RETAINER

SN: B40001-UP

1шт.

9

KD0-35951-0060

PACKING

SN: B40001-UP

2шт.

10

KD0-35926-0090

RETAINER

SN: B40001-UP

1шт.

11

KD1-33926-0730

RETAINER

SN: B40001-UP

1шт.

12

KD0-0275-06802

BOLT

SN: B40001-UP

3шт.

13

KD0-35411-0640

PULLEY

SN: B40001-UP

1шт.

14

KD0-35421-0240

FAN

SN: B40001-UP

1шт.

15

KD1-0330-16012

WASHER, PLAIN

SN: B40001-UP

1шт.

16

KD1-0335-16002

WASHER, SPRING

SN: B40001-UP

1шт.

17

KD0-0280-16022

NUT

SN: B40001-UP

1шт.

18

KD0-35120-0290

FIELD COIL

SN: B40001-UP

1шт.

|19

KD0-35700-0950

REAR BRACKET ASSEMBLY

SN: B40001-UP

1шт.

19

KD0-35710-1150

BRACKET, REAR

SN: B40001-UP

1шт.

20

KD0-35730-0700

RECTIFIER ASSEMBLY

SN: B40001-UP

1шт.

21

KD0-09170-2501

CONDENSER

SN: B40001-UP

1шт.

22

KD0-35943-0150

BUSH, INSULATE

SN: B40001-UP

1шт.

23

KD0-35923-0130

COLLAR

SN: B40001-UP

1шт.

24

KD0-35943-0160

BUSH, INSULATE

SN: B40001-UP

1шт.

25

KD0-35943-0140

BUSH, INSULATE

SN: B40001-UP

1шт.

26

KD0-35943-0170

BUSH, INSULATE

SN: B40001-UP

2шт.

27

KD0-35784-0210

BAR, CONNECT

SN: B40001-UP

1шт.

28

KD0-35784-0290

TERMINAL, PLATE

SN: B40001-UP

1шт.

29

KD0-09057-0220

WASHER

SN: B40001-UP

2шт.

30

KD0-35719-0210

REGULATOR ASSEMBLY

SN: B40001-UP

1шт.

31

KD0-35761-0250

COVER

SN: B40001-UP

1шт.
