Запчасти Komatsu D61EX-15 HSS МОТОР (/) Y [ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|1

708-7L-00060

MOTOR ASSEMBLY

SN: B40001-UP

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1642-01A0 AND Y1642-02A0.

-1шт.

1

0

CASE

SN: B40001-UP

1шт.

|2

0

COVER SUB ASSEMBLY, END

SN: B40001-UP

1шт.

2

0

COVER, END

SN: B40001-UP

1шт.

3

0

SPOOL

SN: B40001-UP

1шт.

4

0

PLUG

SN: B40001-UP

1шт.

5

0

PLUG

SN: B40001-UP

3шт.

6

0

O-RING

SN: B40001-UP

3шт.

7

20B-27-11210

BLEEDER

SN: B40001-UP

1шт.

8

0

VALVE

SN: B40001-UP

2шт.

9

0

SPRING

SN: B40001-UP

2шт.

10

0

PLUG

SN: B40001-UP

2шт.

11

0

O-RING

SN: B40001-UP

2шт.

12

708-7L-16211

RETAINER

SN: B40001-UP

2шт.

13

708-7L-16220

SPRING

SN: B40001-UP

2шт.

14

708-7L-16311

COVER

SN: B40001-UP

2шт.

15

07000-13035

O-RING

SN: B40001-UP

2шт.

16

01010-81035

BOLT

SN: B40001-UP

8шт.

17

01643-51032

WASHER

SN: B40001-UP

8шт.

18

0

O-RING

SN: B40001-UP

1шт.

19

0

PIN

SN: B40001-UP

1шт.

20

0

BOLT

SN: B40001-UP

6шт.

21

0

SHAFT

SN: B40001-UP

1шт.

22

0

BEARING

SN: B40001-UP

1шт.

23

0

BEARING

SN: B40001-UP

1шт.

24

0

SPACER KIT

SN: B40001-UP

1шт.

25

0

SEAL, OIL

SN: B40001-UP

1шт.

26

0

SPACER, 3.2MM

SN: B40001-UP

1шт.

27

0

RING

SN: B40001-UP

1шт.

28

0

BLOCK, CYLINDER

SN: B40001-UP

1шт.

29

0

PLATE, VALVE

SN: B40001-UP

1шт.

30

0

PIN

SN: B40001-UP

1шт.

31

0

PIN

SN: B40001-UP

3шт.

32

0

SEAT

SN: B40001-UP

1шт.

33

0

SPRING

SN: B40001-UP

1шт.

34

0

SEAT

SN: B40001-UP

1шт.

35

0

RING

SN: B40001-UP

1шт.

36

0

GUIDE, RETAINER

SN: B40001-UP

1шт.

37

0

RETAINER, SHOE

SN: B40001-UP

1шт.

38

0

PISTON SUB ASSEMBLY

SN: B40001-UP

9шт.

39

0

PLATE

SN: B40001-UP

1шт.
