Запчасти Komatsu D61EX-15 HSS НАСОС (/) Y [ОСНОВН. КОМПОНЕНТЫ И РЕМКОМПЛЕКТЫ]

|1

708-1L-00380

PUMP ASSEMBLY

SN: B41443-UP

1шт.

|1

708-1L-00350

PUMP ASSEMBLY

SN: B40001-B41442

1шт.

|$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.Y1600-01A0 T0 Y1600-06A0.

-1шт.

|1

0

PUMP SUB ASSEMBLY

SN: B40001-UP

1шт.

1

0

SHAFT

SN: B40001-UP

1шт.

2

0

BEARING

SN: B40001-UP

1шт.

3

0

WASHER KIT

SN: B40001-UP

1шт.

4

0

RING, SNAP

SN: B40001-UP

1шт.

5

708-25-52861

SEAL, OIL

SN: B40001-UP

1шт.

6

708-2L-22160

SPACER

SN: B40001-UP

1шт.

7

04065-06825

RING, SNAP

SN: B40001-UP

1шт.

|8

0

BLOCK ASSEMBLY, REAR

SN: B40001-UP

1шт.

8

0

BLOCK, CYLINDER

SN: B40001-UP

1шт.

9

0

PLATE, VALVE

SN: B40001-UP

1шт.

10

0

PIN

SN: B40001-UP

1шт.

11

0

RING, SNAP

SN: B40001-UP

1шт.

12

0

SEAT

SN: B40001-UP

1шт.

13

0

SPRING

SN: B40001-UP

1шт.

14

0

SEAT

SN: B40001-UP

1шт.

15

0

GUIDE, RETAINER

SN: B40001-UP

1шт.

16

0

PIN

SN: B40001-UP

3шт.

17

0

RETAINER, SHOE

SN: B40001-UP

1шт.

18

0

PISTON SUB ASSEMBLY

SN: B40001-UP

9шт.

|19

0

CRADLE ASSEMBLY

SN: B40001-UP

1шт.

19

0

CRADLE

SN: B40001-UP

1шт.

20

0

CAM, ROCKER

SN: B40001-UP

1шт.

21

0

PIN

SN: B40001-UP

1шт.

22

0

O-RING

SN: B40001-UP

1шт.

23

0

BOLT

SN: B40001-UP

4шт.
