Запчасти Komatsu D61EX-15 КАБИНА (ВОЗД.-CONDITIONER ВОЗДУХОВОДЫ) K [КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ]

|1

17A-Z11-0042

CAB ASSEMBLY

SN: B40001-UP

1шт.

|1

17A-Z11-0062

CAB ASSEMBLY, (RADIO LESS)

SN: B40001-UP

1шт.

|1

17A-Z11-0072

CAB ASSEMBLY, (RADIO LESS, HEAT GLASS)

SN: B40001-UP

1шт.

|1

17A-Z11-0102

CAB ASSEMBLY, (AM/FM RADIO)

SN: B40001-UP

1шт.

|1

17A-Z11-0112

CAB ASSEMBLY, (AM/FM CASSETTE STEREO)

SN: B40001-UP

1шт.

|1

17A-Z11-0122

CAB ASSEMBLY, (RADIO AM/FM AND CASSETTE)

SN: B40001-UP

1шт.

|$7

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.K0210

SN: B40001-UP

-1шт.

|1

17A-Z11-3800

DUCT ASSEMBLY

SN: B40001-UP

1шт.

1

0

DUCT

SN: B40001-UP

1шт.

2

17A-Z11-3821

SEAL

SN: B40001-UP

1шт.

3

17A-Z11-3831

SEAL

SN: B40001-UP

1шт.

4

17A-Z11-3781

SHEET

SN: B40001-UP

2шт.

5

17A-Z11-3841

PLATE

SN: B40001-UP

1шт.

6

17A-Z11-3890

BRACKET

SN: B40001-UP

1шт.

7

01245-00835

SCREW

SN: B40001-UP

2шт.

8

01643-70823

WASHER

SN: B40001-UP

8шт.

9

01245-00816

SCREW

SN: B40001-UP

6шт.

10

17A-Z11-3871

DUCT

SN: B40001-UP

1шт.

11

17A-Z11-3881

DUCT

SN: B40001-UP

1шт.

12

01245-00616

SCREW

SN: B40001-UP

8шт.

13

01643-70623

WASHER

SN: B40001-UP

8шт.

14

17A-Z11-7161

LOUVER

SN: B40001-UP

3шт.

15

01370-10312

SCREW

SN: B40001-UP

2шт.

16

01370-10412

SCREW

SN: B40001-UP

4шт.

17

17A-Z11-3961

PLATE

SN: B40001-UP

1шт.

18

22U-06-22250

CONVERTER

SN: B40001-UP

1шт.

19

01245-00620

SCREW

SN: B40001-UP

2шт.

20

01643-70623

WASHER

SN: B40001-UP

2шт.
