Запчасти Komatsu D61E-12 МАРКИРОВКА (КИТАЙ) (DE) МАРКИРОВКА

1

134-98-61120

PLATE, MARK,D61E

SN: 1001-UP

2шт.

2

09690-B0224

PLATE, MARK,KOMATSU, FRONT

SN: 1001-UP

1шт.

3

09690-C0800

PLATE, MARK,KOMATSU, REAR

SN: 1001-UP

1шт.

4

134-98-61212

OIL CHART

SN: 1170-UP

1шт.

4

134-98-61210

OIL CHART

SN: 1001-1169

1шт.

5

0

PLATE,(LIMITED SUPPLY)

SN: 1173-UP

1шт.

5

0

PLATE, NAME,(LIMITED SUPPLY)

SN: 1001-1172

1шт.

5

0

PLATE,(LIMITED SUPPLY)

SN: 1001-UP

1шт.

5

04418-13060

SCREW

SN: 1001-UP

4шт.

6

124-98-51140

PLATE, OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: 1001-UP

1шт.

7

134-54-66190

PLATE,PROTECTION FILM

SN: 1163-UP

1шт.

8

134-54-66290

PLATE,PROTECTION FILM

SN: 1163-UP

1шт.

9

14X-98-11240

PLATE, OPERATING,STEERING LEVER (C AND B)

SN: 1001-UP

1шт.

10

14X-98-12570

PLATE,PRESSURE TEST (C AND B)

SN: 1001-UP

1шт.

11

09653-A0481

PLATE, SAFETY,CAUTION OIL AND WATER

SN: 1001-UP

2шт.

12

09657-A0881

PLATE, SAFETY,ADJUSTING TRACK TENSION

SN: 1001-UP

2шт.

13

09651-A0641

PLATE, SAFETY,READ OPERATION MANUAL

SN: 1001-UP

1шт.

14

09802-19000

PLATE, SAFETY,SAFETY IN REAR

SN: 1001-UP

1шт.

15

09654-B0641

PLATE, SAFETY,CAUTION AFTER OPERATING

SN: 1001-UP

1шт.

16

17A-98-11180

PLATE,HORN

SN: 1001-UP

1шт.

17

14X-98-11170

PLATE, OPERATING,LOCK

SN: 1001-UP

2шт.

18

09637-90263

PLATE, INSTRUCTION,AIR CLEANER

SN: 1001-UP

1шт.

19

09963-09001

TAG,DO NOT OPERATE

SN: 1001-UP

1шт.

20

09806-B1201

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 1001-UP

2шт.

21

09667-A0641

PLATE, SAFETY,REVOLVING OBJECT CAUTION

SN: 1001-UP

2шт.

22

09808-A0881

PLATE, SAFETY,BATTERY CABLE

SN: 1001-UP

1шт.

23

09669-0000E

PLATE, CAUTION,DIESEL FUEL

SN: 1170-UP

1шт.
